Type SF Lighting Capacitors, 90 °C Rated, Oil Filled
AC Rated, Oil Filled/Impregnated, Metallized Polypropylene Capacitors
For better performance in HID Lighting and HV Ballasts, Type SF oval
and round oil filled metallized polypropylene lighting capacitors are
built for operating in the high temperature environments for high
intensity discharge (HID) lighting and other high voltage ballast
applications. Each HID catalog capacitor includes an external resistor
that discharges the capacitor to less than 50V in one minute, and the
oil filled process assures better reliability than dry capacitors.
Highlights
Specifications
Capacitance Range
Capacitance Tolerance
Rated Voltage
Operating Temperature Range with Ripple
Operating Frequency
±3%
–40 ºC to +90 ºC
50 - 60 Hz
RoHS Compliant
280 Vac to 525 Vac, other voltages available
N
Case Material
Encapsulation
Dimensions
Click here to view hardware
Construction Details
Round Case Style
or
Terminal Material
.81 ± .06
D ±.06
as
es
no
H
+.12
–.06
tf
Case Code
P
S
T
D (Inches)
1.87
2.12
2.62
H
Oval
Case Code
A
B
C
D
A
1.31
1.56
1.91
1.97
ew
Aluminum or Tin Plated Steel
Enviromentally Safe Dielectric Fluid
Tin Plated Steel
Oval Case Style
D
Dimensions (Inches)
B
2.16
2.69
2.91
3.66
H
See Ratings Table
See Ratings Table
See Ratings Table
See Ratings Table
K
Terminals
K = 2-tine with
fork and external
resistor, 90 ºC
5.0 µF to 55 µF
See Ratings Table
See Ratings Table
See Ratings Table
Part Numbering System
ee
SF
lC
C
40
Voltage
T
Case Matl.
T=Aluminum
w/steel cover
S = Steel
15
Cap
7 = 7.0 µF
32 = 32.0 µF
19.5 = 19.5 µF
L
Tolerance
L = ±3%
291
Can Height
291 = 2.91
391 = 3.91
Type
SF
Case Size
A = 1 1/4" Oval
28 = 280 Vac
30 = 300 Vac
33 = 330 Vac
40 = 400 Vac
52 = 525 Vac
St
B = 1 1/2" Oval
C = 1 3/4" Oval
D = 2.0" Oval
S = 2.0" Round
T = 2 1/2" Round
P = 1 3/4" Round 48 = 480 Vac
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830
es
-F
RoHS
Compliant
- Casing: aluminum standard, tin-plated steel optional
- Paint: (U. L. recognized) optional
- Meets EIA Standard EIA-456-A
