construction combined with new, high performance materials. This
combination of advanced technologies allows Cooper Bussmann to offer a
wide variety of capacitor solutions tailored to specific applications that range
from a few micro-amps for several days to several amps for milliseconds.
HF
Pb
FREE
Cylindrical Device
HALOGEN
Features & Benefits
• 5.0 Volts
• Low ESR
• High capacitance
• Long cycle life
• Low leakage currents
• UL Recognized
Applications
• Bridge or hold-up power
• Memory backup
• Battery swap out
Specifications
Working Voltage
Surge Voltage
Capacitance
Capacitance Tolerance
Operating Temperature Range
5.0V
6.0V
0.1F to 1.0F
-20% to +80% (20°C)
-25°C to 70°C
Standard Product
Nominal
Capacitance
Part Numbers
(F)
Vertical
Horizontal
0.1
PB-5R0V104-R
PB-5R0H104-R
0.47
PB-5R0V474-R
PB-5R0H474-R
1.0
PB-5R0V105-R
PB-5R0H105-R
Maximum ESR (Ω)
(Equivalent Series Resistanc)
Measured @ 100Hz
4.0
1.0
0.5
Nominal Leakage
Current (μA) After
72 Hours @ 20°C
3
7
12
Nominal Dimensions (mm)
5.5 x 10.8 x 12.5
8.5 x 16.8 x 14.0
8.5 x 16.8 x 21.5
Typical Mass
(grams/piece)
1.1
2.4
3.5
Performance
Parameter
Life (1000 hrs @ 70°C @ 5.0Vdc)
Storage - Low and High Temperature
(1000 hrs @ -25°C and 70°C)
Capacitance Change
(% of initial measured value)
<
30 %
<
30 %
ESR
(% of initial specified value)
<
300 %
<
300 %
1211
BU-SB111358
Page 1 of 2
Data Sheet: 4393
Dimensions (mm)
Horizontal Part #
PB-5R0H104-R
PB-5R0H474-R
PB-5R0H105-R
Tolerances
Note:
Longer lead is positive.
Vertical Part #
PB-5R0V104-R
PB-5R0V474-R
PB-5R0V105-R
A
6.0
9.0
9.0
B
11.3
17.3
17.3
Maximum
C
13.0
14.5
22.0
d’
0.5
0.5
0.5
± 0.02
D
20
20
20
D’
E
15
25
15
25
15
25
Minimum
E’
20
20
20
F
2.0
2.0
2.0
P
7.3
11.8
11.8
± 0.5
B
C
A
d'
B
F
C
A
d'
C
A
C
A
F
D'
P
D
E
Positive lead
P
P
E'
Positive lead
V
e
rtic
a
l
Part Numbering System
P
Series
Code
P Series
Horizont
a
l
B
Version
High Capacitance
−
5
R
Voltage (V)
R = Decimal
5R0 = 5.0V
0
Configuration
V = Vertical
H = Horizontal
Capacitance (μF)
Value
Multiplier
4
Example: 474 = 47 x 10 µF or 0.47F
Packaging Information
Packaging:
• Standard packaging: Bulk, 100 units per bag.
• Larger bulk packages available on request.
Part Marking
Manufacturer
Capacitance (F)
Max Operating Voltage (V)
Series Code (or part number)
Polarity
North America
Cooper Bussmann
1225 Broken Sound Parkway NW
Suite F
Boca Raton, FL 33487-3533
Tel: 1-561-998-4100
Fax: 1-561-241-6640
Toll Free: 1-888-414-2645
Cooper Bussmann
P.O. Box 14460
St. Louis, MO 63178-4460
Tel: 1-636-394-2877
Fax: 1-636-527-1607
Europe
Cooper Bussmann
Cooper (UK) Limited
Burton-on-the-Wolds
Leicestershire • LE12 5TH UK
Tel: +44 (0) 1509 882 737
Fax: +44 (0) 1509 882 786
Cooper Bussmann
Avda. Santa Eulalia, 290
08223
Terrassa, (Barcelona), Spain
Tel: +34 937 362 812
+34 937 362 813
Fax: +34 937 362 719
Asia Pacific
Cooper Bussmann
1 Jalan Kilang Timor
#06-01 Pacific Tech Centre
Singapore 159303
Tel: +65 278 6151
Fax: +65 270 4160
