BA3924 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> BA3924

BA3924: DescriptionSPECIALTY ANALOG CIRCUIT, PSIP12; CategoryAnalog mixed-signal IC The signal circuit; File Size162KB，12 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA3924 Overview

SPECIALTY ANALOG CIRCUIT, PSIP12

BA3924 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SIP
package instruction	SIP-12
Contacts	12
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	R-PSIP-T12
JESD-609 code	e3/e2
length	29.8 mm
Number of terminals	12
Maximum operating temperature	85 °C
Minimum operating temperature	-33 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SIP
Encapsulate equivalent code	SIP12,.1
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	260
power supply	12 V
Certification status	Not Qualified
Maximum seat height	15.3 mm
Maximum supply current (Isup)	110 mA
Maximum supply voltage (Vsup)	22 V
Minimum supply voltage (Vsup)	5 V
Nominal supply voltage (Vsup)	12 V
surface mount	NO
technology	BIPOLAR
Temperature level	OTHER
Terminal surface	TIN/TIN COPPER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	SINGLE
Maximum time at peak reflow temperature	10
width	4.7 mm

Preview

Download Datasheet

View All

Regulator ICs

Power supply for CD radio cassette

players

BA3924

The BA3924 is a system reference power supply for use in CD radio cassette players. Outputs dedicated to a micropro-

cessor (5.0V), CD player (7.5V), audio system (7.5V), and motor drive (9V) are built in. Also built in is a V

output

that allows turning ON and OFF the supply voltage by HIGH and LOW levels of the standby pin.

FApplications

CD radio cassette players

FFeatures

1) With outputs dedicated to a microcontroller, CD play-

er, audio system, and motor drive, the IC is best

suited for CD radio cassette players.

2) Zero standby current (typ.).

3) Output current limit circuit protects the IC against

short-circuiting damage.

4) Compact 12-pin package allows large power dissipa-

tion.

5) Thermal shutdown circuit protects the IC against

thermal damage.

6) V

output allows turning ON and OFF the power

supply voltage by HIGH and LOW levels of the stand-

by pin.

FAbsolute

maximum ratings (Ta = 25_C)

FRecommended

operating conditions (Ta = 25_C)

141
