BA3918 datasheet, PDF - EEWORLD Datasheet

BA3918: DescriptionSystem power supply for car stereos; CategoryAnalog mixed-signal IC The signal circuit; File Size143KB，9 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA3918 Overview

System power supply for car stereos

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SIP
package instruction	POWER, SIP-12
Contacts	12
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	R-PSIP-T12
JESD-609 code	e3/e2
length	29.8 mm
Number of terminals	12
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SIP
Encapsulate equivalent code	SIP12,.1
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	260
power supply	13.2 V
Certification status	Not Qualified
Maximum seat height	15.3 mm
Maximum supply voltage (Vsup)	16 V
Minimum supply voltage (Vsup)	10 V
Nominal supply voltage (Vsup)	13.2 V
surface mount	NO
technology	BIPOLAR
Temperature level	OTHER
Terminal surface	TIN/TIN COPPER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	SINGLE
Maximum time at peak reflow temperature	10
width	4.7 mm

Regulator ICs

System power supply for car stereos

BA3918

The BA3918 is a single-chip power supply IC for use in car audio systems. One 5.6V output for a microcontroller, three

8.7V outputs, and two outputs interlocked by BACKUP and ACC systems are built in.

FApplications

Car audio systems

FFeatures

1) All outputs except AMP and ANT use a PNP transis-

tor with a low saturation voltage.

2) Output current limit circuit prevents damage to the IC

due to short-circuiting.

3) Overvoltage protection circuit provides protection

against surges from the A

CC

or BACKUP input.

4) Compact 12-pin POWER package allows large pow-

er dissipation.

5) Thermal protection circuit prevents heat damage to

the IC.

FBlock

diagram

242
