BA3911 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> BA3911

BA3911: DescriptionReference voltage power supply; CategoryAnalog mixed-signal IC The signal circuit; File Size151KB，10 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA3911 Overview

Reference voltage power supply

BA3911 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SFM
package instruction	SIP-12
Contacts	12
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	R-XSFM-T12
Number of functions	1
Number of terminals	12
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Package body material	UNSPECIFIED
Encapsulate equivalent code	SIP12,.1
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	13.2 V
Certification status	Not Qualified
Maximum supply voltage (Vsup)	16 V
Minimum supply voltage (Vsup)	10 V
Nominal supply voltage (Vsup)	13.2 V
surface mount	NO
technology	BIPOLAR
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

Regulator ICs

Reference voltage power supply

BA3911

The BA3911 is a single-chip power supply IC for use in car audio systems. One 5.6V output for microcontrollers, three

8.7V outputs, and two outputs interlocked with BACKUP and ACC systems are built in.

FApplications

Car audio systems

FFeatures

1) A power supply IC for car audio systems ; one 5.6V

output for microcontrollers, three 8.7V outputs, and

two outputs interlocked with BACKUP and ACC sys-

tems are built in.

2) All output circuits use a PNP transistor with a low sat-

uration voltage.

3) Output current limit circuit prevents damage to the IC

in the event output is short-circuited.

FBlock

diagram

4) Overvoltage protection circuit provides protection

against surges from the ACC or BACKUP inputs.

5) Compact 12-pin POWER package allows a large

power dissipation.

6) Thermal protection circuit prevents heat damage to

the IC.

216
