BA5210FS datasheet, PDF - EEWORLD Datasheet

BA5210FS: DescriptionSpeaker / headphone switch power amplifier; CategoryAnalog mixed-signal IC Consumption circuit; File Size127KB，8 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA5210FS Overview

Speaker / headphone switch power amplifier

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	SSOP-16
Contacts	16
Reach Compliance Code	compli
ECCN code	EAR99
Commercial integrated circuit types	AUDIO AMPLIFIER
Gain	35 dB
harmonic distortion	10%
JESD-30 code	R-PDSO-G16
JESD-609 code	e3/e2
length	6.6 mm
Number of channels	2
Number of functions	1
Number of terminals	16
Maximum operating temperature	60 °C
Minimum operating temperature	-10 °C
Nominal output power	0.45 W
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Encapsulate equivalent code	SOP16,.25,32
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	3.3 V
Certification status	Not Qualified
Maximum seat height	1.6 mm
Maximum slew rate	14 mA
Maximum supply voltage (Vsup)	6 V
Minimum supply voltage (Vsup)	2.5 V
surface mount	YES
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal surface	TIN/TIN COPPER
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	4.4 mm
Base Number Matches	1

Audio ICs

Speaker / headphone switch power

amplifier

BA5210FS

The BA5210FS is a power amplifier with a built-in monaural speaker / stereo headphone switch. The speaker drive is

BTL for large output, and when the headphones are connected, the “center-amp” design means that coupling is not re-

quired. This significantly reduces the number of external components required, and makes this IC ideal for compact sets

that have high component density. Mute and standby functions are provided, and direct microprocessor control is pos-

sible.

FApplications

Notebook computers, electronic books, portable CD

players, video cameras with built-in monitors, LCD TVs,

radios, and electronic instruments

FFeatures

1) Built-in BTL / stereo switch circuit.

2) Mute function.

3) Standby function.

FBlock

diagram

4) Few external components required.

5) Low current dissipation and good sound quality.
