BA5913FP-Y: Description4-channel BTL driver for CD players and CD-ROM drives; CategoryOther integrated circuit (IC) Consumption circuit; File Size132KB，9 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BA5913FP-Y Overview

4-channel BTL driver for CD players and CD-ROM drives

BA5913FP-Y Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	HSSOP,
Contacts	25
Reach Compliance Code	unknow
Commercial integrated circuit types	CONSUMER CIRCUIT
JESD-30 code	R-PDSO-G25
length	13.6 mm
Number of functions	1
Number of terminals	25
Maximum operating temperature	85 °C
Minimum operating temperature	-35 °C
Package body material	PLASTIC/EPOXY
encapsulated code	HSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	2.11 mm
Maximum slew rate	20 mA
Maximum supply voltage (Vsup)	6.6 V
Minimum supply voltage (Vsup)	4.3 V
surface mount	YES
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	5.4 mm

Preview

Download Datasheet

View All

Optical disc ICs

4-channel BTL driver for CD players

and CD-ROM drives

BA5913FP-Y

The BA5913FP-Y is an IC with an internal 4-channel BTL driver for CD players and CD-ROM driver actuators and mo-

tors, as well as an internal standard operational amplifier. In addition, the 25-pin HSOP package allows for application

miniaturization.

FApplications

CD players, CD-ROM drives

FFeatures

1) 4-channel BTL driver.

2) Wide dynamic range (typically 3.6V when V

CC

= 5V

and RL = 8Ω).

3) Internal thermal shutdown circuit.

4) Gain is adjustable with attached resistor.

5) Internal standard operational amplifier.

6) Can enter power save mode with standby pin.

7) HSOP 25-pin power package allows for application

miniaturization.

FAbsolute

maximum ratings (Ta = 25_C)

FRecommended

operating conditions (Ta = 25_C)

533
