BA6297AFP datasheet, PDF - EEWORLD Datasheet

BA6297AFP: Description4-channel BTL driver for CD players; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size100KB，6 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA6297AFP Overview

4-channel BTL driver for CD players

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	SSOP,
Contacts	28
Reach Compliance Code	unknow
Is Samacsys	N
Interface integrated circuit type	CD MOTOR DRIVER
JESD-30 code	R-PDSO-G28
length	18.5 mm
Number of terminals	28
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	2.41 mm
surface mount	YES
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.5 mm
Base Number Matches	1

Optical disc ICs

4-channel BTL driver for CD players

BA6297AFP

The BA6297AFP is a 4-channel BTL driver for CD player actuators and motors. The preamplifier has both positive and

negative input pins and output pins, making this IC suited to a broad range of applications.

FApplications

CD players

FFeatures

1) 4-channel BTL driver.

2) HSOP 28-pin package allows for miniaturization of

applications.

3) Internal thermal shutdown.

4) Driver gain is adjustable with a single attached resis-

tor.

5) Both positive and negative input pins, for adaptability

for a wide range of inputs (including negative phase

input).

FAbsolute

maximum ratings (Ta = 25_C)

FRecommended

operating conditions (Ta = 25_C)

318
