CRCA
Vishay Dale
Thick Film Array, Resistor/Capacitor
FEATURES
•
Single component reduces board space and
•
•
•
•
•
•
•
component counts
Choice of dielectric characteristics X7R or Y5U
Wrap around termination
Thick film R/C element
Inner electrode protection
Flow & Reflow solderable
Automatic placement capability, standard size
8 or 10 pin configurations
STANDARD ELECTRICAL SPECIFICATIONS
RESISTOR
GLOBAL POWER RATING
MODEL
P
70
°C
W
CRCA12E
CRCA12S
CRCA12E
CRCA12S
0.125
0.125
TEMPERATURE TOLERANCE
COEFFICIENT
ppm/°C
%
200
200
5
5
VALUE
RANGE
Ω
10R - 1M0
10R - 1M0
DIELECTRIC
X7R
Y5U
CAPACITOR
TEMPERATURE TOLERANCE VOLTAGE
COEFFICIENT
RATING
%
%
VDC
± 15
+ 20, - 56
20
20
50
50
VALUE
RANGE
pF
10 - 270
270 - 1800
RESISTOR
•
Operating Temperature Range: X7R - 55 °C to + 125 °C
•
Technology: Thick Film
Notes
•
Ask about extended value ranges
•
Packaging: according to EIA 481
CAPACITOR
•
Operating Temperature Range: X7R - 55 °C to + 125 °C
Y5U - 30 °C to + 85 °C
•
Maximum Dissipation Factor: 2.5 %
•
Dielectric Withstanding Voltage: 125 V
dc
, 5 sec, 50 mA Charge
•
Power rating depends on the max. temperature at the solder point,
the component placement density and the substrate material
TECHNICAL SPECIFICATIONS
PARAMETER
Rated Dissipation at 70 °C
(CECC 40401 I EIA 575)
Capacitor Voltage Rating
Dielectric Withstanding
Voltage (5 sec, 50 mA Charge)
Category Temperature Range
Insulation Resistance
UNIT
W
V
V
dc
°C
Ω
RESISTOR
0.125
-
-
- 55/+ 155
X7R CAPACITOR
-
50
125
- 55/+ 125
> 10
10
Y5U CAPACITOR
-
50
125
- 30/+ 85
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: CRCA12E081472220R (preferred part numbering format)
C
MODEL
CRCA12E
CRCA12S
R
C
A
1
2
E
0
8
1
4
7
2
2
2
0
R
PIN COUNT SCHEMATIC
08
=
8
Pin
10
= 10 Pin
1
= 01
2
= 02
3
= 03
0
= Special
RESISTANCE
CAPACITANCE
PACKAGING
SPECIAL
VALUE
VALUE
2 digit significant
2 digit significant
E
= Lead (Pb)-free, T/R (2000 pcs) (Dash
Number)
figures, followed
by
figures, followed
by
(up to 1 digit)
R
= Tin/Lead, T/R (2000 pcs)
a multiplier
multiplier
Blank = Standard
100
= 10
Ω
100
= 10 pF
683
= 68 kΩ
271
= 270 pF
105
= 1.0 MΩ
182
= 1800 pF
(Tolerance = ± 5
%)
(Tolerance = ± 20
%)
Historical Part Number example: CRCA12E0801472J220MRB8 (will continue to be accepted)
CRCA12E
MODEL
08
PIN COUNT
01
SCHEMATIC
472
RESISTANCE
VALUE
J
TOLERANCE
220
CAPACITANCE
VALUE
M
TOLERANCE
RB8
PACKAGING
www.vishay.com
280
For technical questions, contact: ff2aresistors@vishay.com
Document Number: 31044
Revision: 15-Jan-07
CRCA
Thick Film Array, Resistor/Capacitor
Vishay Dale
DIMENSIONS
8-Terminal
device
S-Version
E-Version
a
e
GLOBAL
MODEL
CRCA12E
CRCA12S
CRCA12E
CRCA12S
PIN
NO#
8
8
10
10
SIZE
INCH METRIC
2012
5032
2012
5032
2512
6432
2512
6432
L
5.1 ± 0.15
5.1 ± 0.15
6.4 ± 0.15
6.4 ± 0.15
W
3.05 ± 0.15
3.05 ± 0.15
3.05 ± 0.15
3.05 ± 0.15
T
0.61 ± 0.10
0.61 ± 0.10
0.61 ± 0.10
0.61 ± 0.10
DIMENSIONS
[in millimeters]
B
B*
A
A*
D
NOM
0.51 ± 0.25 0.38 ± 0.2 0.79 ± 0.15
-
0.25
0.51 ± 0.25 0.38 ± 0.2 0.79 ± 0.15 0.89 ± 0.15 0.25
0.51 ± 0.25 0.38 ± 0.2 0.79 ± 0.15
-
0.25
0.51 ± 0.25 0.38 ± 0.2 0.79 ± 0.15 0.89 ± 0.15 0.25
a
0.71
0.71
b
1.05
0.86
P
NOM
1.27
1.27
1.27
1.27
e
1.09
1.09
WAVE SOLDERING
REFLOW SOLDERING
SOLDER PAD DIMENSIONS
[in millimeters]
c
w
d
p
2.2
4.3
0.57
1.27
2.2
3.9
0.57
1.27
Note
1. The images shown are for an 8 pin Part. For a 10 pin part, use the same pitch and add another pair of “a” dimension pads to the inner solder
pads.
SCHEMATICS
01 Circuit
CRCA12E & S
02 Circuit
CRCA12E & S
03 Circuit
CRCA12E & S
Rated Power in
%
120
100
80
60
40
20
0
- 55
10 Pin only
10 Pin only
8 Pin
10 Pin
- 25
0
25
50
Derating
75
100
125
150 175
70
Ambient Temperature in
°C
PERFORMANCE
TEST
Endurance Test at 70 °C MIL-Std-202 Method 108
Dielectric Withstanding Voltage MIL-Std-202
Method 301
Thermal Shock MIL-Std-202 Method 107
Moisture MIL-Std-202 Method 106
Resistance to Soldering Heat EIA 575
High Temperature Exposure EIA 575
Low Temperature Operation EIA 575
Solderability & Leaching EIA 575 3.12
CONDITIONS OF TEST
1000 hours at 70 °C, 1.5 hours "ON", 0.5 hours "OFF"
125 V
dc
, 5 seconds, 50 mA charge
100 cycles, - 55 to + 125 °C
Omit steps 7A and B
10 seconds at 260 °C solder bath temperature
125 °C for 100 hours
1 hour at - 55 °C then 45 minutes at 50 V
Condition C
TEST RESULTS
R
± (5 % + 2
Ω)
C
± 20 %
no physical damage
± (5 % + 2
Ω)
± (5 % + 2
Ω)
± (5 % + 2
Ω)
± (5 % + 2
Ω)
± (5 % + 2
Ω)
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
95 % Coverage
APPLICABLE SPECIFICATIONS
• IPC Standards
• EIA 575
Document Number: 31044
Revision: 15-Jan-07
For technical questions, contact: ff2aresistors@vishay.com
www.vishay.com
281
