SHEET 1 OF 1
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
3.17
[.125 in]
5.08
[.200 in]
1.27
[.050 in]
12.70
[.500 in]
5.08
[.200 in]
3
6
4.70
[.185 in]
2
5
ON
2-3, 5-6
NONE
N/A
ON
2-1, 5-4
.85
[.033 in]
2.70
[.106 in]
.55
[.022 in]
11.43
[.450 in]
KEYWAY
n
1.85
1
4
[.073 in]
12.70
[.500 in]
n
6.35
(8)
P.C.B. LAYOUT
3.81
[.150 in]
2
5
1
3
4
6
PANEL MOUNTING
6.10
[.240 in]
[.094 in]
n
2.38
With Locking
Ring
[.250]
POS. 1
T6 ACTUATOR
2/BUILT IN
ANTI-ROTATION
CIRCUIT: DPDT
POS. 3
5.08
[.200 in]
25
~
12.30
[.484 in]
.41
[.016 in]
7.55
[.297 in]
n
6.35
[.250 in]
With Standard
Locking Ring
1/4-40 UNS-2A
THREADS
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: SILVER
5. RATING: 5 Amps @120VAC (or 28 VDC),
2 Amps @250VAC
6. LIFE EXPECTANCY: 40,000 MAKE-AND-BREAK CYCLES
(Min.) AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.
9. OPERATING TEMP.: -30°C to 85°C
10.
DENOTES CRITICAL PARAMETER.
11. 2002/95/EC (ROHS) COMPLIANT
12. HARDWARE TO BE SHIPPED BULK
T100000 - HEXNUT - QTY 2
T100011 - LOCKWASHER - QTY 1
T100015 - LOCKRING - QTY 1
A
REV
18002
PCR NO
RELEASE FOR PRODUCTION
DESCRIPTION
E-SWITCH
MARKING ON
OPPOSITE SIDE
10.41
[.410 in]
1.44
[.057 in]
1.27
[.050 in]
3
12.70
[.500 in]
4
5
6
.76
[.030 in]
9.40
[.370 in]
EPOXY
SEAL
4.70
[.185 in]
6
3.81
[.150 in]
3/11/08
DATE
BLR
BY
TITLE
SCALE
100DP1T6B11M6QEH
2:1
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
3/11/2008
DR
BLR
DWG
ST121107
REV
A
