NG8QN&NG8QW
NG8QN&NG8QW
Operation condition
Insulation Resistance
Dielectric Strength
Between contacts
Between contact and coil
Shock resistance
Vibration resistance
Terminals strength
Solderability
Ambient Temperature
Relative Humidity
Mass
100M
min (at 500VDC)
Item 7 of IEC 61810-5
Item 6 of IEC 61810-5
Item 6 of IEC 61810-5
IEC68-2-27 T Ea
est
IEC68-2-6 T Fc
est
IEC68-2-21 Test Ua1
IEC68-2-20 Test Ta method 1
IEC68-2-3 Test Ca
50Hz 500V
50Hz 500V
100m/s
2
11ms
10~55Hz double amplitude 1.5mm
5N
235
2
3 0.5s
-40~105
85% (at 40 )
5.5g
16.0 12.5 14.4
16.0 25.5 14.4
Features
Small size, light weight.
Low coil consumption.
PC board mounting.
Suitable for household electrical appliances, automobile system, window,wipe motor ,hours, doorlock.
Dimensions
1.5
4- 1.3
0.051
mm /inch
Ordering Information
1
2
3
4
5
6
4 Contact rating 15A,20A/14VDC
5 Coil rated voltage(V) DC:12
6 Coil power consumption 0.69:0.69W
NG8QN
3.5 0.5
3.138 0.020
NG8QN C
S
10 DC12V 0.69
1 Part number NG8QN NG8QW
2 Contact arrangement C:1C U:IU
NG8QW 2C:2C,2U:2U
3 Enclosure S: Sealed type NIL: Dust cover
0.5
0.020
14.4max.
0.567max.
5
5
0.1970.197
16max.
0.630max.
12.5max..
0.492max..
0.059
2.5
0.098
10.2
0.401
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or Voltage drop
Operation
life
Electrical
Mechanical
1C SPDT(B-M) ,1U SPSTNODM ,2C DPDT ,2U DPSTNODM
AgCdO AgSnO
2
15A, 20A/14VDC
inrush current 30A (L/R=7mS; 15mS max)
280W
16VDC
Max. Switching Current:20A
100m
Item 4.12 of IEC 61810-7
250mV(at10A)
Item 4.12 of IEC 61810-7
10
5
Item 4.30 of IEC 61810-7
10
7
Item 4.31 of IEC 61810-7
1.6
0.062
5-1.1 0.4
0.039 0.016
2- 1.5
0.059
0.020
14.4max.
0.567max.
0.1970.197
5
5
16max.
0.630max.
0.5
25.5max.
1.004max,
8- 1.3
0.051
0.5
0.020
Coil Parameter
Coil voltage
VDC
Rated
Max.
Coil
resistance
10%
Pickup
voltage
VDC(max)
(61%of rated
voltage )
Release
voltage
VDC(min)
(7.5% of rated
voltage)
Coil power
consumption
W
Operate
Time
ms
Release
Time
ms
1.6
0.062
10-1.1 0.4
0.039 0.016
2.5
0.098
0.1970.197
3.5
NG8QW
3.138
5
5
10.2
0.401
Dimensions
Mounting (Bottom view)
Dash
numbers
012-690
12
16
210
7.3
9.0(at 80 )
0.9
0.69
10
5
CAUTION:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
Wiring diagram(Bottom view)
NOTES 1).Dimensions are in millimeters.
2).Inch equivalents are given for general information only.
163
23.0
0.906
Ningbo Huaguan Electronics Corporation LTD.
