SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Alchip
TM
Standard, 85℃
-
・φ4
through
φ18
case sizes are fully lined up
・Endurance
: 2,000 hours at 85℃
・Suitable
to fit for downsized equipment
・Solvent
resistant type except 100 to 450V
dc
(see PRECAUTIONS AND GUIDELINES)
・RoHS
Compliant
MVA
Series
MVA
105℃
MVE P70
◆SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Characteristics
-40 to +85
℃
4 to 450V
dc
(at 20
℃
, 120Hz)
±20%
(M)
Rated voltage (V
dc
)
4 to 100V
160 to 450V
D55 to JA0 I=0.01CV or 3µA, whichever is greater.(after 2 minutes)
-
KE0 to MN0 I=0.03CV or 4µA, whichever is greater.(after 1 minute)
I=0.04CV+100µA max.(after 1 minute)
Where, I : Max. leakage current (µA), C : Nominal capacitance (µF), V : Rated voltage (V)
(at 20
℃
)
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
D55 to JA0 0.42 0.35 0.30 0.26 0.16 0.14 0.12 0.12 0.12
-
-
tan (Max.)
δ
KE0 to MN0 -
0.38 0.34 0.30 0.26 0.22 0.18 0.14 0.10
0.20
0.25
When nominal capacitance exceeds 1,000µF, add 0.02 to the value above for each 1,000µF increase.
(at 20
℃
, 120Hz)
Rated voltage (V
dc
)
4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
Z(-25
℃
)/Z(+20
℃
)
3
2
2
2
2
2
3
4
7
-
-
D55 to JA0
Z(-40
℃
)/Z(+20
℃
) 17
4
3
3
3
4
6
8
10
-
-
Z(-25
℃
)/Z(+20
℃
) -
2
2
2
2
2
3
4
5
3
6
KE0 to MN0
Z(-40
℃
)/Z(+20
℃
) -
(at 120Hz)
3
3
3
4
5
8
10
12
6
10
The following specifications shall be satisfied when the capacitors are restored to 20
℃
after the rated voltage is applied for 2,000 hours
at 85
℃
.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage (V
dc
)
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦
±30%
of the initial value
≦
±20%
of the initial value
D.F. (tan )
δ
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20
℃
after exposing them for 1,000 hours at 85
℃
without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Size code
D55 to JA0
D55 to JA0
KE0 to MN0
Rated voltage
4V & 6.3V
10 to 100V
6.3 to 450V
Capacitance change
≦
±30%
of the initial value
≦
±20%
of the initial value
D.F. (tan )
δ
≦200%
of the initial specified value
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
≦The
initial specified value
Dissipation Factor
(tanδ)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Shelf Life
◆DIMENSIONS
[mm]
●
Terminal Code :
●
Size code : D55
Vent
(Except D55 to HA0)
φD
±
0.5
B
±
0.2
A
to MN0
W
●
Terminal
●
Size
Vent
φD
±
0.5
Code : G (Vibration resistant structure)
code : LH0 to MN0
Size code
0.3max.
W
D55
E55
F55
F80
HA0
JA0
KE0
KG5
LH0
LN0
MH0
MN0
0.3max.
L
±
0.3(Note)
A
±
0.2
L
±
0.5
A
±
0.2
Note : L±0.5 for HA0 to MN0
: Dummy terminals
◆MARKING
D55 to JA0
EX) 16V47µF
7hA
◆RATED
RIPPLE CURRENT MULTIPLIERS
D
4
5
6.3
6.3
8
10
12.5
12.5
16
16
18
18
L
5.2
5.2
5.2
7.7
10.0
10.0
13.5
16.0
16.5
21.5
16.5
21.5
A
4.3
5.3
6.6
6.6
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
B
4.3
5.3
6.6
6.6
8.3
10.3
13.0
13.0
17.0
17.0
19.0
19.0
C
5.1
5.9
7.2
7.2
9.0
11.0
13.7
13.7
18.0
18.0
20.0
20.0
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
1.0 to 1.3
P
1.0
1.4
1.9
1.9
3.1
4.5
4.2
4.2
6.5
6.5
6.5
6.5
P
C
±
0.2
B
±
0.2
47
16V
KE0 to HN0
EX) 25V1,000µF
1000
25V
0V
MVA
P
C
±
0.2
・Frequency
Multipliers
Size code
D55 to JA0
Frequency(Hz)
Capacitance(μF)
1.0
2.2 to 10
22 to 1,500
4.7
10 to 68
100 to 1,000
2,200 to 10,000
120
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1k
1.50
1.30
1.05
1.75
1.50
1.30
1.05
10k 100k
1.75
1.40
1.08
2.30
1.75
1.40
1.08
1.80
1.50
1.08
2.50
1.80
1.50
1.08
◆PART
NUMBERING SYSTEM
E MV A
AAA A AA AAA
M
AAA N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0µF:1R0,100µF:101)
Taping·Tray code
Terminal code (A, G)
Voltage code (ex. 6.3V:6R3,100V:101,450V:451)
Series code
Category
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
KE0 to MN0
The endurance of capacitors is reduced with internal
heating produced by ripple current at the rate of halving
the lifetime with every 5℃ rise.
When long life performance is required in actual use, the
rms ripple current has to be reduced.
Please refer to "Product code guide (surface mount type)"
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
68
CAT. No. E1001N
