BA6832FS datasheet, PDF - EEWORLD Datasheet

BA6832FS: DescriptionVoice coil motor driver; CategoryOther integrated circuit (IC) The signal circuit; File Size98KB，8 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BA6832FS Overview

Voice coil motor driver

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SSOP
package instruction	SSOP, SOP24,.3,32
Contacts	24
Reach Compliance Code	unknow
ECCN code	EAR99
Analog Integrated Circuits - Other Types	VOICE COIL MOTOR CONTROLLER
JESD-30 code	R-PDSO-G24
length	10 mm
Number of functions	1
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature	-25 °C
Maximum output current	1.2 A
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SOP24,.3,32
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	12 V
Certification status	Not Qualified
Maximum seat height	1.9 mm
Maximum supply current (Isup)	15 mA
Maximum supply voltage (Vsup)	13.8 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	12 V
surface mount	YES
technology	BIPOLAR
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	5.4 mm

Motor driver ICs

Voice coil motor driver

BA6832FS

The BA6832FS is a voice coil motor driver used for moving the heads of hard disc and mass-storage floppy disc drives.

FApplications

HDD disc and mass-storage FDD

FFeatures

1) Output current is controlled by the Vctl-Vref voltage.

2) Retraction control pin.

FAbsolute

maximum ratings (Ta = 25_C)

3) Chip enabling pin.

4) Internal thermal shutdown circuit.

FRecommended

operating conditions

509
