TA12-150-18 Overview

DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,

TA12-150-18 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Semiconductor Circuits Inc
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (main output)	85%
Maximum input voltage	36 V
Minimum input voltage	9 V
Nominal input voltage	18 V
JESD-30 code	R-XDMA-P6
Maximum grid adjustment rate	0.25%
Maximum load regulation	0.5%
Number of functions	1
Output times	1
Number of terminals	6
Maximum operating temperature	71 °C
Minimum operating temperature	-25 °C
Maximum output voltage	13.2 V
Minimum output voltage	10.8 V
Nominal output voltage	12 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	CURRENT; OUTPUT OVER VOLTAGE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL EXTENDED
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	18 W
Fine-tuning/adjustable output	YES

Preview

Download Datasheet

View All

765432121098765432109876543210987654321

ENVIRONMENTAL

GENERAL

OUTPUT

INPUT

All specifications are typical at nominal line and full load at 25°C unless

otherwise noted and are subject to change without notice.

Ripple and Noise

Short Circuit Protection

Temperature Coefficient

Regulation:

Line

Load

Efficiency

I/O Isolation

Switching Frequency

Operating Temperature

Storage Temperature

Cooling

Voltage Tolerance

Filtering

Reverse Polarity Protected

Voltage Range

Remote On/Off Control

Main

0.5%

1.0%

77% (typ)

500 Vdc

100khz (typ)

-25°C to +71°C No Derating

-25°C to +105°C

Free-air Convection

± 1% Main

± 3% Auxiliary

50mV pk-pk

Continuous Power Cycle

0.02% / °C

9-36Vdc

20-72Vdc

All Models

To Nominal Input Current

External Fuse Required

All Models

TA Series

Aux

3.0%

4:1 ultra wide input range

9-36 Vdc

20-72 Vdc

Remote shutdown

100kHz switching frequency

Continuous short circuit

protection

Six-sided shielding

These units are ideally suited for

telecommunications and applications

having a widely varying input voltage

such as automotive test equipment,

process control, minicomputers and

geosurvey equipment.

Applications

he 18-Watt TA series operates

over an ultra wide input range of

9-36 Vdc or 20-72 Vdc. Efficien-

cies of 77% are typical over varying

load conditions of 25% to 100%.

Additional features include input

reverse polarity protection, remote on/

off control, logic compatible with CMOS

or open collector TTL, short circuit

protection with auto restart, overvoltage

protection, and an operating tempera-

ture range of -25°C to +71°C with no

derating. Units are packaged in a six-

sided continuous shielded case for

EMI/RFI protection and measure 2.5” x

3.0” x 0.83”.

Single/Dual/Triple Outputs

18 Watts

TA12-150-18 Related Products

	TA12-150-18	TA13-120-18	TA11-350-18	TA11-350-48	TA23-120-48	TA12-150-48	TA13-120-48	TA23-120-18
Description	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 2 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 1 Output, 18W, Hybrid,	DC-DC Regulated Power Supply Module, 2 Output, 18W, Hybrid,
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	unknow	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE	DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (main output)	85%	85%	85%	85%	85%	85%	85%	85%
Maximum input voltage	36 V	36 V	36 V	72 V	72 V	72 V	72 V	36 V
Minimum input voltage	9 V	9 V	9 V	20 V	20 V	20 V	20 V	9 V
Nominal input voltage	18 V	18 V	18 V	48 V	48 V	48 V	48 V	18 V
JESD-30 code	R-XDMA-P6	R-XDMA-P6	R-XDMA-P6	R-XDMA-P6	R-XDMA-P8	R-XDMA-P6	R-XDMA-P6	R-XDMA-P8
Maximum grid adjustment rate	0.25%	0.25%	0.25%	0.25%	0.25%	0.25%	0.25%	0.25%
Maximum load regulation	0.5%	0.5%	0.5%	0.5%	0.5%	0.5%	0.5%	0.5%
Number of functions	1	1	1	1	1	1	1	1
Output times	1	1	1	1	2	1	1	2
Number of terminals	6	6	6	6	8	6	6	8
Maximum operating temperature	71 °C	71 °C	71 °C	71 °C	71 °C	71 °C	71 °C	71 °C
Minimum operating temperature	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C
Maximum output voltage	13.2 V	16.5 V	5.5 V	5.5 V	15.15 V	13.2 V	16.5 V	15.15 V
Minimum output voltage	10.8 V	13.5 V	4.5 V	4.5 V	14.85 V	10.8 V	13.5 V	14.85 V
Nominal output voltage	12 V	15 V	5 V	5 V	15 V	12 V	15 V	15 V
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Protect	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE	CURRENT; OUTPUT OVER VOLTAGE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO	NO	NO	NO	NO
technology	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED
Terminal form	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Maximum total power output	18 W	18 W	18 W	18 W	18 W	18 W	18 W	18 W
Fine-tuning/adjustable output	YES	YES	YES	YES	NO	YES	YES	NO
Maker	Semiconductor Circuits Inc	Semiconductor Circuits Inc	Semiconductor Circuits Inc	Semiconductor Circuits Inc	-	Semiconductor Circuits Inc	Semiconductor Circuits Inc	Semiconductor Circuits Inc
