BR2501 Overview

25 A, SILICON, BRIDGE RECTIFIER DIODE

Suntan Su
®
®
BR25005 THRU BR2510
Single Phase 25 AMPS.Silicon Bridge Rectifiers
Voltage Range 50 to 1000 Volts
FEATU R E S
Ideal for printed circuit board
Reliable low cost construction technique
Current 25 Amperes
BR
results in inexpensive product
High temperature soldering guaranteed:
260
/ 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs., ( 2.3 kg ) tension
◆UL
Recognized File number: E347215
MECHANICAL DATA
Case: Molded plastic
Lead: solder plated
Polarity: As marked
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.For capacitive load, derate current by 20%
Type Number
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
BR
25005
BR
2501
100
70
100
BR
2502
200
140
200
BR
2504
400
280
400
BR
2506
600
420
600
BR
2508
800
560
800
BR
2510
1000
700
1000
UNITS
V
V
V
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
Maximum Average Forward Rectified Current
@T
C
= 55℃
Peak Forward Surge Current,
8.3ms Single Half Sine-wave Superimposed on
Rated Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@12.5A
Maximum DC Reverse Current
at Rated DC Blocking voltage per Element
25
A
I
FSM
V
F
I
R
R
θJC
T
J
T
STG
400
A
1.1
5.0
1.5
-55 to +125
-55 to +150
V
μA
/W
Typical Thermal Resistance (Note1)
Operating Temperature Range
Storage Temperature Range
Note:
1.
Thermal Resistance from junction to case with units mounted on a 5" x 6" x 4.9" (12.8cm.x 15.2cm.x 12.4cm.) Al.-Finned Plate
