Power Inductors - Shielded
ctparts.com
CTCDRH105RF Series
From 6.8 µH to 1000 µH
SPECIFICATIONS
Parts are available in ±30% tolerance only.
*This indicates the current when the inductance decreases to 65% over it’s nominal value
or D.C. current when the temperature rises
ΔT=40°C
lower, whichever is lower.
Part
Number
CTCDRH105RF-6R8N
CTCDRH105RF-100N
CTCDRH105RF-120N
CTCDRH105RF-150N
CTCDRH105RF-180N
CTCDRH105RF-220N
CTCDRH105RF-270N
CTCDRH105RF-330N
CTCDRH105RF-390N
CTCDRH105RF-470N
CTCDRH105RF-560N
CTCDRH105RF-680N
CTCDRH105RF-820N
CTCDRH105RF-101N
CTCDRH105RF-121N
CTCDRH105RF-151N
CTCDRH105RF-181N
CTCDRH105RF-221N
CTCDRH105RF-271N
CTCDRH105RF-331N
CTCDRH105RF-391N
CTCDRH105RF-471N
CTCDRH105RF-561N
CTCDRH105RF-681N
CTCDRH105RF-821N
Inductance
(µH ±30%)
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
18.0
25.8
32.0
40.0
46.0
58.5
65.4
81.4
103.1
122.1
144.8
193.0
219.4
247.0
298.4
355.1
394.3
483.8
632.5
780.0
957.5
1220.4
1352.4
1519.2
1694.4
1946.4
*Rated DC
Current
(A)
5.40
4.50
4.00
3.60
3.20
2.95
2.70
2.40
2.30
2.00
1.90
1.65
1.50
1.35
1.28
1.12
1.04
0.94
0.84
0.75
0.70
0.60
0.54
0.52
0.50
0.48
Not shown at actual size.
Compliant
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±30%
Testing:
Tested on a HP4285A at 100 KHz , 0.25Vrms , 0Adc
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTCDRH105RF-102N
PHYSICAL DIMENSIONS
Size
mm
inches
Max.
10.3
0.406
A
Max.
10.5
0.413
B
Max.
5.1
0.201
C
D
3.0±0.1
0.12±0.003
E
7.7±0.3
0.30±0.01
F
1.2±0.15
0.05±0.006
A
C
XXX
B
PAD LAYOUT
D
Marking
(Inductance Code)
Unit: mm
1
E
1.6
7.3
10.5
F
2
3.2
02.12.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
