Power Inductors - Shielded
ctparts.com
CTCDRH124 Series
From 3.9 µH to 330 µH
ENGINEERING KIT #23F
Not shown at actual size.
Part
Number
CTCDRH124_-3R9N
CTCDRH124_-4R7N
CTCDRH124_-6R8N
CTCDRH124_-8R2N
CTCDRH124_-100M
CTCDRH124_-120M
CTCDRH124_-150M
CTCDRH124_-180M
CTCDRH124_-220M
CTCDRH124_-270M
CTCDRH124_-330M
CTCDRH124_-390M
CTCDRH124_-470M
CTCDRH124_-560M
CTCDRH124_-680M
CTCDRH124_-820M
CTCDRH124_-101M
CTCDRH124_-121M
CTCDRH124_-151M
CTCDRH124_-181M
CTCDRH124_-221M
CTCDRH124_-271M
CTCDRH124_-331M
SPECIFICATIONS
Part numbers indicate tolerance available.
N = ±30% , M = ±20%
CTCDRH124F
Please specify “F” for RoHS Compliant
L Test
DCR
Inductance
Freq.
Max.
Ω
(µH)
(kHz)
(Ω)
3.9
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
.02
.02
.02
.03
.03
.04
.05
.06
.07
.08
.10
.13
.16
.19
.22
.26
.31
.38
.53
.62
.70
.87
.99
IDC
Max.
(A)
6.5
5.7
4.9
4.6
4.5
4.0
3.2
3.1
2.9
2.8
2.7
2.1
1.9
1.8
1.5
1.3
1.2
1.1
1.0
0.9
0.8
0.6
0.5
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-25°C to +80°C
Inductance Tolerance:
±20%, ±30%
Testing:
Inductance is tested on an HP4284A at 100 kHz
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code.
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
Max.
12.5
0.492
A
Max.
4.5
0.18
B
C
7.6
0.299
D
5.0
0.197
A
B
D
XXX
C
Marking
(Inductance Code)
08.01.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
