Power Inductors - Shielded
ctparts.com
CTCDRH127 Series
From 1.2 µH to 1,000 µH
ENGINEERING KIT #32F
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTCDRH127-560_
J = ±5%, K = ±10% L = ±15% M = ±20%, N = +40% -20%
CTCDRH127F
Please specify “F” for RoHS compliant
L Test
Freq.
(kHz)
100
100
100
100
100
100
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
Max.
Ω
(mΩ)
7.0
11.5
13.5
15.8
17.6
20.0
21.6
24.3
27.0
39.2
43.2
45.9
64.8
72.9
100
110
140
160
220
250
280
350
390
560
640
700
980
1070
1460
1640
1820
IDC
Max.
(A)
9.80
8.00
7.50
6.80
6.60
5.90
5.40
4.90
4.50
3.90
3.60
3.40
3.00
2.75
2.50
2.35
2.10
1.95
1.70
1.60
1.42
1.30
1.16
1.06
0.95
0.88
0.79
0.73
0.67
0.60
0.55
Part
Number
CTCDRH127_-1R2N
CTCDRH127_-2R4N
CTCDRH127_-3R5N
CTCDRH127_-4R7N
CTCDRH127_-6R1N
CTCDRH127_-7R6N
CTCDRH127_-100M
CTCDRH127_-120M
CTCDRH127_-150M
CTCDRH127_-180M
CTCDRH127_-220M
CTCDRH127_-270M
CTCDRH127_-330M
CTCDRH127_-390M
CTCDRH127_-470M
CTCDRH127_-560_
CTCDRH127_-680_
CTCDRH127_-820_
CTCDRH127_-101_
CTCDRH127_-121_
CTCDRH127_-151_
CTCDRH127_-181_
CTCDRH127_-221_
CTCDRH127_-271_
CTCDRH127_-331_
CTCDRH127_-391_
CTCDRH127_-471_
CTCDRH127_-561_
CTCDRH127_-681_
CTCDRH127_-821_
CTCDRH127_-102_
Inductance
(µH)
1.2
2.4
3.5
4.7
6.1
7.6
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±5%, ±10%, ±15%, ±20%, +40% -20%
Testing:
Inductance is tested on an HP4284A at specified
frequency
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
12.5
0.492
B
8
0.314
C
7.6±0.2
0.3±0.007
D
5±0.2
0.2±0.007
A(max.)
B(max.)
D
XXX
A(max.)
C
Marking
(Inductance Code)
05.18.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
