Power Inductors - Shielded
ctparts.com
CTCDRH3D16 Series
From 1.5 µH to 100 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±30% tolerance only.
CTCDRH3D16F
Please specify “F” for RoHS Compliant
Inductance
@ 0.25Vrms,0Adc
(µH ±30%)
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
82
100
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.052
.072
.085
.105
.170
.210
.295
.430
.675
.940
1.28
1.55
1.75
*Rated DC
Current
(A)
1.55
1.20
1.10
0.90
0.73
0.55
0.45
0.40
0.32
0.22
0.20
0.17
0.15
CTCDRH3D16_-1R5N
CTCDRH3D16_-2R2N
CTCDRH3D16_-3R3N
CTCDRH3D16_-4R7N
CTCDRH3D16_-6R8N
CTCDRH3D16_-100N
CTCDRH3D16_-150N
CTCDRH3D16_-220N
CTCDRH3D16_-330N
CTCDRH3D16_-470N
CTCDRH3D16_-680N
CTCDRH3D16_-820N
CTCDRH3D16_-101N
Compliant
Available
RoHS
*The rated current indicates the current when the inductance decreases to 65% over its nominal value or D.C.
current when the temperature rising
∆T=40°C
lower, whichever is lower.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
4.1
0.16
B
Max.
4.1
0.16
C
Max.
1.8
0.07
D
1.15
0.05
E
5.2
0.20
F
2.95
0.12
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±30%
Testing:
Tested on a HP4285A at 100kHz
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
A
B
C
D
XXX
Marking:
Inductance Code
F
E
PAD LAYOUT
Unit: mm
1.
1.
4
1.
4
5
2.4
11.03.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
