BA8206F datasheet, PDF - EEWORLD Datasheet

BA8206F: DescriptionTone ringer IC for telephone set; CategoryWireless rf/communication Telecom circuit; File Size90KB，6 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BA8206F Overview

Tone ringer IC for telephone set

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	LSOP, SOP8,.25
Contacts	8
Reach Compliance Code	compli
JESD-30 code	R-PDSO-G8
JESD-609 code	e3/e2
length	5 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	LSOP
Encapsulate equivalent code	SOP8,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE
Peak Reflow Temperature (Celsius)	260
power supply	24 V
Certification status	Not Qualified
Maximum seat height	1.6 mm
Maximum slew rate	0.0017 mA
Nominal supply voltage	24 V
surface mount	YES
technology	BIPOLAR
Telecom integrated circuit types	TELEPHONE RINGER CIRCUIT
Temperature level	COMMERCIAL EXTENDED
Terminal surface	TIN/TIN COPPER
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	4.4 mm

Communication ICs

Tone ringer IC for telephone set

BA8206 / BA8206F

The BA8206 and BA8206F are tone ringer ICs which produce a bell sound from a ringing signal. The frequency of the

bell sound can be varied by changing the constants of the external resistance and capacitors.

The operation initiation current dissipation can be changed at the RSL pin.

Also, the output load can be selected, as a piezoelectric buzzer, a transformer coupled speaker, or other similar devices.

FApplications

Telephones, multi-function telephones, telephone answering machines, facsimiles, equipment involving telephones

FFeatures

1) Low current dissipation.

2) Withstands up to 40V.

3) Operation initiation current dissipation can be

changed using RSL pin.

FBlock

diagram

4) Pin layout is compatible with the BA8205, BA6565A,

and ML8205.

252

	BA8206F	BA8206
Description	Tone ringer IC for telephone set	Tone ringer IC for telephone set
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Parts packaging code	SOIC	DIP
package instruction	LSOP, SOP8,.25	DIP-8
Contacts	8	8
Reach Compliance Code	compli	compli
JESD-30 code	R-PDSO-G8	R-PDIP-T8
JESD-609 code	e3/e2	e3/e2
length	5 mm	9.3 mm
Number of functions	1	1
Number of terminals	8	8
Maximum operating temperature	75 °C	75 °C
Minimum operating temperature	-25 °C	-25 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LSOP	DIP
Encapsulate equivalent code	SOP8,.25	DIP8,.3
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE	IN-LINE
Peak Reflow Temperature (Celsius)	260	260
power supply	24 V	24 V
Certification status	Not Qualified	Not Qualified
Maximum seat height	1.6 mm	3.7 mm
Maximum slew rate	0.0017 mA	0.0017 mA
Nominal supply voltage	24 V	24 V
surface mount	YES	NO
technology	BIPOLAR	BIPOLAR
Telecom integrated circuit types	TELEPHONE RINGER CIRCUIT	TELEPHONE RINGER CIRCUIT
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED
Terminal surface	TIN/TIN COPPER	TIN/TIN COPPER
Terminal form	GULL WING	THROUGH-HOLE
Terminal pitch	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	10	10
width	4.4 mm	7.62 mm
