Ordering number: EN5329
Monolithic Linear IC
LA6540M
4-output Power Operational Amplifier
Overview
The LA6540M is a 4-output power operational amplifier
developed for use in consumer and industrial equipment.
Package Dimensions
unit : mm
3097-MFP16FS
[LA6540M]
Functions
.
High output current (I max = 0.7 A : typ)
.
Includes a current limiter
.
Wide operating voltage range (±2 to
±16
V)
.
Single-supply operation possible (4 to 32 V)
.
Thermal shutdown built in
O
SANYO : MFP16FS
Specifications
Maximum Ratings
at Ta = 25 °C
Parameter
Maximum supply voltage
Input voltage
Allowable power dissipation
Operating temperature
Storage temperature
Symbol
V
CC
/V
EE
V
IN
Pd max
Topr
Tstg
Conditions
Ratings
±18
±17
0.7
–20 to +75
–40 to +150
Unit
V
V
W
°C
°C
Operation Characteristics
at Ta = 25 °C, V
CC
= +15 V, V
EE
= –15 V
Parameter
No-load current drain
Input offset voltage
Input offset current
Input bias current
Input common-mode voltage
range
Common-mode signal rejection
ratio
Maximum output voltage
Slew rate
Limiting current (built in)
Symbol
I
CC
V
IO
I
IO
I
B
V
ID
CMRR
V
O
SR
I
SC
R
L
= 33
Ω
R
L
= 33
Ω,
R1 = 2.2
Ω,
C1 = 0.1 µF
Conditions
Mute OFF
R
S
%
10 kΩ
min
typ
15
2
10
50
max
30
7
100
300
+13
75
±12
0.15
0.7
Unit
mA
mV
nA
nA
V
dB
V
V/µs
A
–14
60
±11
0.5
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
22896HA (II) No.5329-1/4
LA6540M
Allowable power dissipation, Pd max − W
Specifications of specified board
25
×
25
×
1.65 mm
3
Material: Glass epoxy
With specified board
Copper foiled area:
100 mm
2
Independent IC
Ambient temperature, Ta — °C
No products described or contained herein are intended for use in surgical implants, life-support systems, aerospace equipment,
nuclear power control systems, vehicles, disaster/crime-prevention equipment and the like, the failure of which may directly or
indirectly cause injury, death or property loss.
Anyone purchasing any products described or contained herein for an above-mentioned use shall:
1
Accept full responsibility and indemnify and defend SANYO ELECTRIC CO., LTD., its affiliates, subsidiaries and distributors
and all their officers and employees, jointly and severally, against any and all claims and litigation and all damages, cost and
expenses associated with such use:
2
Not impose any responsibility for any fault or negligence which may be cited in any such claim or litigation on SANYO
ELECTRIC CO., LTD., its affiliates, subsidiaries and distributors or any of their officers and employees jointly or severally.
Information (including circuit diagrams and circuit parameters) herein is for example only; it is not guaranteed for volume
production. SANYO believes information herein is accurate and reliable, but no guarantees are made or implied regarding its use
or any infringements of intellectual property rights or other rights of third parties.
This catalog provides information as of February, 1996. Specifications and information herein are subject to change without notice.
No.5329-4/4
