WDM
Pump/Signal WDM
Parameter
Insertion Loss (Pass Band)
Insertion Loss (Reflect Band)
Isolation (Pass Band)
Isolation (Reflect Band)
Return Loss
Directivity
PDL
PMD
Maximum Power Handling
Operating Temperature
Storage Temperature
Package Dimension
980/1550 nm
1480/1550 nm
≤
0.8 dB (1520-1600 nm)
≤
0.7 dB (1530-1580 nm)
≤
0.7 dB (930-1000 nm)
≤
0.6 dB (1440-1490 nm)
≥
30 dB
≥
18 dB
≥
12 dB
≥
50 dB
≥
55 dB
≤
0.1 dB
≤
0.05 ps
300 mW
- 0° C ~ + 65° C
- 40° C ~ + 85° C
Bare Fiber (B)
5.5 mm (Φ) x 35 mm (L)
900µm loose tube (L)
5.5 mm (Φ) x 39 mm (L)
Note 1: All values specified are without connectors.
Note2: Higher performance specifications are available upon request.
Note3: Fiber Type – Corning SMF-28e.
Note4: Over operating temperature, all SOP.
W D
-
-
C: C band reflection
L: L band reflection
Fiber Length
A: 1 meter
B: 1.5 meter
S: Special
-
-
Pigtail Style
(=Package style)
B: bare fiber
L: 900
µm
loose tube
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
www.lighteltech.com
2210 Lind Ave SW, Suite 100
Renton, WA 98057 USA
(425) 277-8000 ph.
(425) 277-5280 Fax
All rights Reserved 2009
