WDM
High Isolation 1310+1490/1550nm FWDM
Parameter
Operating Wavelength Range (Pass Band)
Operating Wavelength Range (Reflect Band)
Insertion Loss (Pass Band)
Insertion Loss (Reflect Band)
Isolation (Pass Band)
Isolation (Reflect Band)
Ripple
Return Loss
Directivity
Maximum Power Handling
Operating Temperature
Storage Temperature
Package Dimension
Specification
1539 – 1565 nm
1260 – 1360 nm & 1480 – 1500 nm
≤ 1.0 dB
≤ 1.0 dB
≥ 45 dB
≥ 45 dB
≤ 0.3 dB
≥ 50 dB
≥ 55 dB
300 mW
- 5° C ~ + 65° C (indoor), - 45° C ~ + 65° C (outdoor)
- 45° C ~ + 85° C
Bare Fiber (B)
5.5 mm () x 35 mm (L)
900 μm loose tube (L)
5.5 mm () x 40 mm (L)
Heavy Duty (K, R)
100.0 mm x 12.0 mm x 8.0 mm
Note 1: All values specified are without connectors.
Note 2: Higher performance specifications available upon request.
Note 3: Fiber Type – Corning SMF-28e unless otherwise specified.
W D H
3
B
1 3
-
-
Fiber Length
A: 1 meter
B: 1.5 meter
S: Special
-
-
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
Temp Range
R: Indoor
E: Outdoor
Pigtail Style
(=Package style)
B: bare fiber
L: 900 μm loose tube
K: 2 mm cable
R: 3 mm cable
www.lightel.com
2210 Lind Ave SW, Suite 100
Renton, WA 98057 USA
(425) 277-8000 ph.
(425) 277-5280 Fax
All rights Reserved 2009
