Power Inductors - Unshielded
ctparts.com
CTDO5022 Series
From 1.0 µH to 1,000 µH
ENGINEERING KIT #11
Not shown at actual size.
Part
Number
CTDO5022P_-102
CTDO5022P_-222
CTDO5022P_-332
CTDO5022P_-562
CTDO5022P_-103
CTDO5022P_-153
CTDO5022P_-223
CTDO5022P_-333
CTDO5022P_-473
CTDO5022P_-683
CTDO5022P_-104
CTDO5022P_-154
CTDO5022P_-224
CTDO5022P_-334
CTDO5022P_-474
CTDO5022P_-684
CTDO5022P_-105
SPECIFICATIONS
Parts are available in ±20% inductance tolerance only.
CTDO5022PF
Please specify “F” for RoHS Compliant
Inductance
(µH)
1.0
2.2
3.3
5.6
10
15
22
33
47
68
100
150
220
330
470
680
1000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
SRF
Typ.
(MHz)
80
80
60
40
30
22
20
15
9
8
7
6
5
4
3
2.5
2
DCR
±15%
Ω
(Ω)
.011
.014
.016
.022
.032
.036
.047
.066
.087
.13
.19
.25
.38
.56
.85
1.2
1.8
Isat
(A)
20
16
14
12
10
8.0
7.0
5.5
4.5
3.5
3.0
2.6
2.4
1.9
1.4
1.2
1.0
Irms
(A)
8.6
7.1
6.2
5.3
4.3
4.0
3.5
3.0
2.6
2.3
1.8
1.5
1.2
1.0
.82
.72
.56
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
18.54
0.73
B
Max.
15.24
0.6
C
Max.
7.11
0.28
D
2.54
0.1
E
2.54
0.1
F
12.7
0.5
CHARACTERISTICS
Description:
SMD power inductor
Applications:
DC/DC converters, computers, LCD displays,
telecommunication equipment and PDA palm tops. Designed for
the higher current requirements of portable computers
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Inductance Drop:
10% typically at Isat
Testing:
Inductance is tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Color dots OR Inductance code
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
Parts will be marked with
Significant Digit Dots OR Inductance Code
A
1st significant digit
B
Ind. Code
XXX
2nd significant digit
3rd significant digit
PAD LAYOUT
C
D
E
F
