Power Inductors - Shielded
ctparts.com
CTDS1608 Series
From 1.0 µH to 10,000 µH
Part
Number
CTDS1608C_-102
CTDS1608C_-152
CTDS1608C_-222
CTDS1608C_-332
CTDS1608C_-472
CTDS1608C_-682
CTDS1608C_-103
CTDS1608C_-153
CTDS1608C_-223
CTDS1608C_-333
CTDS1608C_-473
CTDS1608C_-683
CTDS1608C_-104
CTDS1608C_-154
CTDS1608C_-224
CTDS1608C_-334
CTDS1608C_-474
CTDS1608C_-684
CTDS1608C_-105
CTDS1608C_-155
CTDS1608C_-225
CTDS1608C_-335
CTDS1608C_-475
CTDS1608C_-685
CTDS1608C_-825
CTDS1608C_-106
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTDS1608CF
Please specify “F” for RoHS Compliant
Inductance
(µH ±20%)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
8200
10000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
Fact.
Min.
30
30
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
50
50
50
50
50
50
50
Q Test
Freq.
(kHz)
200
200
200
200
200
200
200
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.040
.045
.050
.055
.060
.065
.075
.090
.110
.190
.230
.290
.480
.590
.770
1.4
1.8
2.2
3.4
4.2
8.5
11.0
13.9
25.0
30.5
32.8
IDC
Max.
(A)
3.0
2.8
1.8
1.6
1.4
1.2
1.0
0.8
0.7
0.6
0.5
0.4
0.3
.26
.22
.20
.19
.18
.15
.12
.10
.08
.06
.04
.02
.02
SRF
Typ.
(MHz)
250
125
120
120
105
50
38
33
25
20
20
15
10
9
6
5
4
3
2
2
2
1
1
1
1
0.8
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
DC/DC converters, computers, LCD displays and
telecommunication equipment. Can help achieve significantly
longer battery life in hand held communication devices and other
portable products
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%
Testing:
Inductance and Q are tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Color dots OR Inductance code
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
6.6
0.26
B
Max.
4.45
0.18
C
Max.
2.92
0.12
D
1.02
0.04
E
1.27
0.05
F
4.32
0.17
G
3.05
0.1
Parts will be marked with
Significant Digit Dots OR Inductance Code
A
1st significant digit
B
Ind. Code
PAD LAYOUT
XXX
2nd significant digit
3rd significant digit
C
D
E
G
F
01.14.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
