Power Inductors - Shielded
ctparts.com
CTEP105S Series
From 0.22 µH to 5.0 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
CTEP105SF
Please specify “F” for RoHS compliant
* The actual current when temperature of coil becomes
∆T=40°C
(Ta=20°C)
Inductance
(µH ±20%)
0.22±30%
0.45
0.8
1.3
1.8
2.5
3.2
4.0
5.0
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
1.7
2.4
4.1
5.3
7.5
10.5
12.4
18.0
23.8
*Temp. Rise
Current(typ.)
(A)
19.0
17.7
13.0
11.2
9.0
7.8
7.4
6.2
4.9
CTEP105S_-0R2N
CTEP105S_-0R4M
CTEP105S_-0R8M
CTEP105S_-1R3M
CTEP105S_-1R8M
CTEP105S_-2R5M
CTEP105S_-3R2M
CTEP105S_-4R0M
CTEP105S_-5R0M
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
10.4
.409
B
Max.
10.4
.409
C
Max.
5.6
.22
D
5.5
.217
E
2.9
.114
F
3.8
.150
G
1.4
.055
H
2.6
.102
J
5.5
.217
A
D
C
CHARACTERISTICS
Description:
SMD shielded power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±20%, ±30%
Testing:
Tested on a HP4285A at 100 KHz , 0.25Vrms , 0Adc
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant available.
Marking:
Parts are marked with inductance code
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
B
H
E
F
G
J
PAD LAYOUT
Unit: mm
2.0
H
2.5
3.8 2.9
11.0
8.5
05.25.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
