Power Inductors - Shielded
ctparts.com
CTEP125S Series
From 1.2 µH to 10 µH
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% only.
* This indicates the current when the inductance decreases to 75% over it’s nominal value or DC current
when the temperature rising
ΔT=40°C
lower, whichever is lower.
CTEP125SF Please specify “F” for RoHS compliant
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
2.5
2.5
3.4
5.4
8.0
11.4
13.5
Part
Number
CTEP125S_-1R2M
CTEP125S_-1R5M
CTEP125S_-2R5M
CTEP125S_-4R0M
CTEP125S_-6R0M
CTEP125S_-8R2M
CTEP125S_-100M
Inductance
(µH ±20%)
1.2
1.5
2.5
4.0
6.0
8.2
10
*Current
(A)
17.0
14.0
10.0
8.3
6.7
5.8
5.0
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
12.9
.51
B
Max.
12.9
.51
C
Max.
5.8
.23
D
2.6±.2
.10±.01
E
7.0±.2
.28±.01
F
4.0±.2
.16±.01
G
4.2±.2
H
2.5±.2
0.17±0.1 .10±.01
CHARACTERISTICS
Description:
SMD shielded power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-30°C to +100°C
Storage Temperature:
-30°C to +100°C
Inductance Tolerance:
±20%
Testing:
Tested on a HP4285A at 100 KHz , 0.25Vrms , 0Adc
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PAD LAYOUT
04.03.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
