Laser Cut Inductors
ctparts.com
SPECIFICATIONS
CTLC0402F Series
From 1.0 nH to 100 nH
Part
Number
Not shown at actual size.
Please specify tolerance code when ordering.
CTLC0402-1N0_
C = ±0.2nH, S = ±0.3nH, G = ±2%, J = ±5%
* C or S only **C or J only ***G or J only
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
Test Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
SRF
Min.
(MHz)
6000
6000
6000
6000
6000
5500
5500
5200
4800
4600
4000
3500
2800
2800
2500
2200
2000
1800
1800
1800
1800
1500
1500
1400
1200
DCR
Max.
Ω
(Ω)
0.05
0.06
0.07
0.08
0.09
0.10
0.12
0.15
0.17
0.19
0.30
0.35
0.41
0.45
0.60
0.70
0.80
1.20
1.40
1.70
2.10
2.50
4.00
4.50
5.50
Rated DC
Max.
(mA)
400
400
400
400
400
400
400
360
360
340
320
320
320
320
240
240
200
200
170
150
140
130
120
110
90
Inductance
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
Q
Min.
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Compliant
RoHS
CTLC0402F-1N0_*
CTLC0402F-1N2_*
CTLC0402F-1N5_*
CTLC0402F-1N8_*
CTLC0402F-2N2_*
CTLC0402F-2N7_*
CTLC0402F-3N3_*
CTLC0402F-3N9_**
CTLC0402F-4N7_**
CTLC0402F-5N6_**
CTLC0402F-6N8_**
CTLC0402F-8N2_**
CTLC0402F-10N_***
CTLC0402F-12N_***
CTLC0402F-15N_***
CTLC0402F-18N_***
CTLC0402F-22N_***
CTLC0402F-27N_***
CTLC0402F-33N_***
CTLC0402F-39N_***
CTLC0402F-47N_***
CTLC0402F-56N_***
CTLC0402F-68N_***
CTLC0402F-82N_***
CTLC0402F-R10_***
CHARACTERISTICS
Description:
SMD laser cut inductors
Applications:
Cellular phones, bluetooth, cable modem and other
electronic devices, etc.
Operating Temperature:
-40°C to +100°C
Inductance Tolerances:
±0.2nH, ±0.3nH, ±2% & ±5%
Testing:
Tested on a HP4287A at 100MHz
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.0±0.1
0.04±0.004
B
0.5±0.1
0.02±0.004
C
0.5±0.1
0.02±0.004
D
0.2±0.1
0.008±0.004
PAD LAYOUT
05.15.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
