CTLL1005F-FH Series
From 1.0 nH to 120 nH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLL1005F-FH5N6_
S = ±0.3nH, J = ±5%, K = ±10%
* S or K only, ** J or K only
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
Q
Factor
Typ.
28
28
30
28
30
30
30
31
30
31
31
34
32
31
30
29
28
27
25
25
23
22
18
16
8
8
Q Test
Freq.
(MHz)
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
100
50
SRF
Min.
(MHz)
13500
12000
10500
9400
8700
7700
6800
6300
5700
5100
4550
4100
3750
2950
2600
2350
1950
1750
1700
1650
1300
1250
1150
1000
850
750
DCR
Max.
Ω
(Ω)
.10
.10
.10
.10
.12
.12
.15
.15
.18
.25
.25
.25
.30
.30
.40
.50
.60
.60
1.5
1.8
2.0
2.0
2.2
2.5
2.5
2.5
Rated
DC
(mA)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
200
200
200
200
180
150
100
100
Inductance
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
ENGINEERING KIT #6F
Not shown at actual size.
Compliant
RoHS
CTLL1005F-FH1N0S
CTLL1005F-FH1N2S
CTLL1005F-FH1N5S
CTLL1005F-FH1N8S
CTLL1005F-FH2N2S
CTLL1005F-FH2N7S
CTLL1005F-FH3N3_*
CTLL1005F-FH3N9_*
CTLL1005F-FH4N7_*
CTLL1005F-FH5N6_*
CTLL1005F-FH6N8_**
CTLL1005F-FH8N2_**
CTLL1005F-FH10N_**
CTLL1005F-FH12N_**
CTLL1005F-FH15N_**
CTLL1005F-FH18N_**
CTLL1005F-FH22N_**
CTLL1005F-FH27N_**
CTLL1005F-FH33N_**
CTLL1005F-FH39N_**
CTLL1005F-FH47N_**
CTLL1005F-FH56N_**
CTLL1005F-FH68N_**
CTLL1005F-FH82N_**
CHARACTERISTICS
Description:
Ceramic core, multi-layer chip inductor for high
frequency applications
Applications:
Portable telephones, PMS, pagers and
miscellaneous high frequency circuits
Temperature Coefficient:
+250ppm/°C
Operating Temperature:
-55°C to + 125°C
Inductance Tolerance:
±0.3 nH, ±5% & ±10%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTLL1005F-FHR10_**
CTLL1005F-FHR12_**
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.0±0.15
0.04±0.006
B
0.5±0.15
0.02±0.006
C
0.5±0.15
0.02±0.006
D
0.25±0.1
0.01±0.004
PAD LAYOUT
05.18.09
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2009 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
