CTLL1608 Series
From 1.2 nH to 100 nH
.
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLL16083N3_
S = ±0.3nH, J = ±5%, K = ±10%
* S or K only
** J, K only
CTLL1608F
Please specify “F” for RoHS Compliant
Inductance
(nH)
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
Factor
Min.
40
38
36
34
32
30
32
32
32
32
28
31
30
26
25
30
26
24
20
18
14
18
18
3
Q Test
Freq.
(MHz)
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
SRF
Min.
(MHz)
>6000
>6000
>6000
>6000
>6000
5700
5600
4800
4350
3750
3300
2850
2700
2400
2050
1850
1750
1500
1350
1200
1100
1000
900
830
DCR
Max.
Ω
(Ω)
.10
.10
.12
.16
.20
.22
.25
.28
.29
.30
.33
.35
.40
.45
.50
.55
.60
.65
.70
.90
1.0
1.5
2.0
2.5
Rated
DC
(mA)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
Compliant
Available
RoHS
CTLL1608_-1N2S
CTLL1608_-1N5S
CTLL1608_-1N8S
CTLL1608_-2N2S
CTLL1608_-2N7S
CTLL1608_-3N3_*
CTLL1608_-3N9_*
CTLL1608_-4N7_*
CTLL1608_-5N6_*
CTLL1608_-6N8_**
CTLL1608_-8N2_**
CTLL1608_-10N_**
CTLL1608_-12N_**
CTLL1608_-15N_**
CTLL1608_-18N_**
CTLL1608_-22N_
CTLL1608_-27N_
CTLL1608_-33N_
CTLL1608_-39N_
CTLL1608_-47N_
CTLL1608_-56N_
CTLL1608_-68N_
CTLL1608_-82N_
CTLL1608_-R10_
CHARACTERISTICS
Description:
Ceramic core, multi-layer chip inductor for high
frequency applications
Applications:
Portable telephones, PMS, pagers and
miscellaneous high frequency circuits
Operating Temperature:
-40°C to +100°C
Inductance Tolerance:
±0.3 nH, ±5% & ±10%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant available.
Other values available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.6±0.15
0.06±0.006
B
0.8±0.15
0.03±0.006
C
0.8±0.15
0.03±0.006
D
0.3±0.2
0.01±0.008
PAD LAYOUT
01.14.05
