Series AM10EW-NZ
10 Watt | DC-DC Converter
FEATURES:
•
Efficiency up to 87%
•
Ultra-Wide 4:1 input range
•
Continuous Short Circuit Protection
•
Operating temperature -40
o
C to + 85
o
C
•
On/Off remote control
•
•
•
•
Input Under-voltage Protection
Over Voltage, Over Current Protection
I/O Isolation 1500, 2250 & 3000VDC
No-load power consumption ≤0.12W
Models
Single output
Model
Input Voltage
(V)
Output
Voltage
(V)
Output
Current max
(mA)
I/O Isolation
(VDC)
Capacitive load
max (μF)
Efficiency
(%)
79
82
85
86
87
87
79
82
86
87
87
81
85
85
86
76
80
84
84
85
AM10EW-2403SH30-NZ
9-36
3.3
2400
3000
5400
AM10EW-2405SH30-NZ
9-36
5
2000
3000
5400
AM10EW-2409SH30-NZ
9-36
9
1111
3000
680
AM10EW-2412SH30-NZ
9-36
12
833
3000
470
AM10EW-2415SH30-NZ
9-36
15
667
3000
330
AM10EW-2424SH30-NZ
9-36
24
416
3000
100
AM10EW-4803SH30-NZ
18-75
3.3
2400
3000
5400
AM10EW-4805SH30-NZ
18-75
5
2000
3000
5400
AM10EW-4812SH30-NZ
18-75
12
833
3000
470
AM10EW-4815SH30-NZ
18-75
15
667
3000
330
AM10EW-4824SH30-NZ
18-75
24
416
3000
100
AM10EW-11005S-NZ
40~160
5
2000
1500
2200
AM10EW-11012S-NZ
40~160
12
833
1500
220
AM10EW-11015S-NZ
40~160
15
667
1500
100
AM10EW-11024S-NZ
40~160
24
416
1500
47
AM10EW-11003SH22-NZ
40~160
3.3
2400
2250
5400
AM10EW-11005SH22-NZ
40~160
5
2000
2250
5400
AM10EW-11012SH22-NZ
40~160
12
833
2250
470
AM10EW-11015SH22-NZ
40~160
15
667
2250
330
AM10EW-11024SH22-NZ
40~160
24
417
2250
100
*Add suffix “-ST” for optional screw terminal bottom plate or “-STD” for optional DIN Rail screw terminal bottom plate.
Models
Dual output
Model
AM10EW-2405DH30-NZ
AM10EW-2412DH30-NZ
AM10EW-2415DH30-NZ
AM10EW-4805DH30-NZ
AM10EW-4812DH30-NZ
AM10EW-4815DH30-NZ
Input
Voltage (V)
9-36
9-36
9-36
18-75
18-75
18-75
Output
Voltage
(V)
±5
±12
±15
±5
±12
±15
Output
Current max
(mA)
±1000
±416
±333
±1000
±416
±333
I/O Isolation
(VDC)
3000
3000
3000
3000
3000
3000
Capacitive load
max (μF)
±1000
±330
±220
±1000
±330
±220
Efficiency
(%)
82
86
87
82
86
87
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Input Specifications
Parameters
Voltage range
Input Current (full load)
www.aimtec.com
F 051e R12.H
REV: 08/19/A
Nominal
24
48
110
24
48
Tel: +1 514 620 2722
1 of 7
Typical
9-36
18-75
40~160
Maximum
Units
VDC
521
261
mA
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM10EW-NZ
10 Watt | DC-DC Converter
110
Filter
Input Surge Voltage (1sec max.)
Start-up time
Reflected Input Ripple Current
24
48
110
Nominal Input, resistive load
24
48
110
24
48
110 (2250 Isolated models)
On
Off
(Pi) Network
50
100
180
10
40
30
30
6.5
15.5
33
VDC
ms
mA
117
Under-voltage lockout
Remote On/Off Control (24 & 48Vin)
V
3.5-12VDC or leave open
0-1.2VDC or connect to GND, idle current 5-6mA
Isolation Specifications
Parameters
Tested I/O voltage
Tested I/FG & O/FG
Resistance
Capacitance
Conditions
1 min, <1mA
1 min, <1Ma, 2250VDC I/O isolated models
At 500VDC Isolation
24 & 48 Vin, I/O, 100KHz/0.1V
110 Vin (1500VDC isolation), I/O, 100KHz/0.1V
110 Vin (2250VDC isolation), I/O, 100KHz/0.1V
Typical
Rated
1500, 2250 & 3000
1600
Units
VDC
VDC
MOhm
pF
> 1000
500
1000
2200
Output Specifications
Parameters
Voltage accuracy
Voltage balance (Dual Output Models)
Line voltage regulation
Load voltage regulation
Cross Regulation
Short Circuit protection
Short Circuit restart
Over Voltage Protection
Over Current Protection
Transient Recovery Time
Transient Response Deviation
Temperature coefficient
Ripple & Noise
Conditions
110 Vin (2250VDC isolation), 0-100% load
Others, 5-100% load
Balanced Load
110 Vin (2250VDC isolation), Full Load (HL-LL)
Others, Full Load (HL-LL)
110 Vin (2250VDC isolation), 0-100% load
Others, 5-100% load
50% load on one output & 10-100% load on second
load
Auto Recovery
24 & 48 Vin models
110 Vin (2250VDC isolation)
110 Vin (2250VDC isolation), 25% Load Step Change
Others, 25% Load Step Change
25% Load Step Change
20Mhz bandwidth
Typical
±1
±1
±0.2
±0.5
±0.5
±0.5
Maximum
±3
±2
±0.5
±1
±1
±1.5
±5
Units
%
%
%
%
%
Continuous
120
140
120
300
500
±3
±0.03
60
160
190
210
500
1000
±8
120
% of Vo
% of Io
µs
%
%/
o
C
mV p-p
General Specifications
Parameters
Switching frequency
Conditions
110 Vin (2250VDC isolation), 100% load
Others, 100% load
Derating above 71°C
-55 to +125
Typical
300
350
-40 to +85
Maximum
Units
KHz
o
C
o
C
o
C
Operating temperature
Storage temperature
Max case temperature
Cooling
Humidity
Solder Temp Leads
Case material
Weight
105
Free air convection
Non-condensing
95
1.5 mm from case 10 sec.
300
Plastic (3000VDC Isolated models)
Aluminum Alloy (Others)
24 (3000VDC Isolated models)
Pin mountable
22 (1500VDC Isolated models)
Tel: +1 514 620 2722
2 of 7
%
o
C
g
www.aimtec.com
F 051e R12.H
REV: 08/19/A
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM10EW-NZ
10 Watt | DC-DC Converter
26 (2250VDC Isolated models)
46 (3000VDC Isolated models)
-ST option
44 (1500VDC Isolated models)
48 (2250VDC Isolated models)
66 (3000VDC Isolated models)
-STD option
64 (1500VDC Isolated models)
68 (2250VDC Isolated models)
3000VDC Isolated models
2.03 x 1.04 x 0.47 inches; 51.50 x 26.50 x 12.00mm
Others
2.00 x 1.00 x 0.46 inches; 50.80 x 25.40 x 11.80mm
Optional packages
See dimensions drawing
>1 000 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Dimensions
(L x W x H)
MTBF
Environmental Specifications
Parameters
Vibration (24 & 48 Vin)
Vibration (110 Vin/1500VDC isolation)
Vibration (110 Vin/2250VDC isolation)
Test mode
10-55Hz
Acceleration
10G, 30min one cycle, every axis tested
Test mode
5-150Hz
Acceleration
2G, 30min one cycle, every axis tested
Displacement
7.5mm
IEC61373 car body 1 B mold
Safety Specifications
Parameters
Approvals
CE, UL (3000VDC Isolated models only)
EN/IEC/UL60950-1
EN 55022, class A (all models) and EMI EN50121-3-2 class A (2250 VDC Isolated models)
IEC61000-4-2, Contact ±6KV (110Vin), Contact ±4KV (24 & 48 Vin), Criteria B
IEC61000-4-3, 10V/m, Criteria A
IEC61000-4-4, ±4KV (110Vin), ±2KV (24 & 48 Vin with the recommended EMC circuit), Criteria B
IEC61000-4-5, ±2KV, Criteria B, (with the recommended EMC circuit)
IEC61000-4-6, 3 Vrms, 10 Vrms (2250 VDC Isolated models) Criteria A
IEC61000-4-29, 0-70%, Criteria B
IEC/EN/UL 60950-1
Meets EN50155 (2250 VDC Isolated models)
Standards
Derating
Free Air Convection
71ºC
100
Output Power (%)
80
60
40
20
Safe Operating Area
0
- 40
- 20
0
20
40
60
71
75
80
85
100
Ambient Temperature
º C
www.aimtec.com
F 051e R12.H
REV: 08/19/A
Tel: +1 514 620 2722
3 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
Series AM10EW-NZ
Pin Out Specifications
3000VDC Isolated models
Pin
1
2
3
4
5
6
10 Watt | DC-DC Converter
Dimensions 3000VDC Isolated models
51.50
(2.03)
7.62 5.08
(0.30) (0.20)
On/Off Control
-Vin
+Vin
- Vout
No pin
+ Vout
10.16
(0.40)
6
3
10.16
(0.40)
10.16
(0.40)
20.32
(0.80)
15.24
(0.60)
20.32
(0.80)
26.50
(1.04)
Bottom View
2
5
Pin
1
2
3
4
5
6
Dual
On/Off Control
-Vin
+Vin
- Vout
Common
+ Vout
12.00
(0.47)
15.24
(0.60)
DIA
1.00
(0.04)
Notes:
All dimensions are typical in
millimeters (inches).
Pin diameter Tolerance ±0.10 (±0.004)
Case Tolerance ±0.50 (±0.02)
Pin Out Specifications
Other models
Pin
1
2
3
4
Dimensions of Other models
50.80
(2.00)
Single
Vin -
Vin +
+Vout
-Vout
4.10
(0.16)
3
25.40
(1.00)
5.08
(0.20)
20.32
(0.80)
Bottom View
1
4
Built-in Stand-offs to
ease PCB cleaning
50.8
(2.00)
Notes:
All dimensions are typical
in millimeters (inches).
Tolerance ±0.25 (±0.01)
DIA
1.00
(0.04)
www.aimtec.com
F 051e R12.H
REV: 08/19/A
11.80
(0.47)
Tel: +1 514 620 2722
4 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
25.4
(1.00)
2
2.54
(0.10)
1
4
2.54
(0.10)
Single
Series AM10EW-NZ
Dimensions with -ST options
76.00
(2.99)
61.60
(2.43)
10 Watt | DC-DC Converter
Pin Out Specifications
Pin
LED light
Single
N.C.
-Vin
+Vin
+ Vout
N.C.
- Vout
1
31.50
(1.24)
6
5
4
23.00
(0.91)
2
3
Top view
1
2
3
4
5
6
3000VDC Isolated models
Pin
Dimensions: mm (inch)
Case Tolerance:± 0.50 (0.02)
Wire gauge: 24-12AWG
Single
On/Off Control
-Vin
+Vin
- Vout
No pin
+ Vout
Dimensions with -STD options
76.00
(2.99)
61.60
(2.43)
8.80
(0.35)
21.20
(0.84)
Side view
1
2
3
4
5
6
Pin Out Specifications
Pin
LED light
Single
N.C.
-Vin
+Vin
+ Vout
N.C.
- Vout
1
31.50
(1.24)
6
5
4
Ø3.30
Ø0.13
2
3
23.00
(0.91)
Top view
1
2
3
4
5
6
3000VDC Isolated models
Pin
1
2
3
4
5
6
Single
On/Off Control
-Vin
+Vin
- Vout
No pin
+ Vout
Side view
9.80
(0.39)
25.80
(1.02)
Dimensions: mm (inch)
Case Tolerance:± 1.00 (0.04)
Wire gauge: 24-12AWG
CY1
1nF/2KV
LCM
22mH
EMC recommended filter 110Vin models
+Vin
F1
R1
C1
C2
D1
+Vo
C3
DC-DC Converter
-Vo
MOV
-Vin
CY2
1nF/2KV
www.aimtec.com
F 051e R12.H
REV: 08/19/A
Tel: +1 514 620 2722
5 of 7
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
