Power Inductors - Shielded
ctparts.com
CTMP2 Series
From 0.47 µH to 47 µH
Part
Number
CTMP2_-R47
CTMP2_-1R0
CTMP2_-1R5
CTMP2_-2R2
CTMP2_-3R3
CTMP2_-4R7
CTMP2_-6R8
CTMP2_-100
CTMP2_-150
CTMP2_-220
CTMP2_-330
CTMP2_-470
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only
CTMP2F
Please specify “F” for RoHS Compliant
Inductance
(µH)
.47
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
OCL
(µH±20%)
0.40
1.02
1.59
2.29
3.58
4.60
7.02
9.95
15.30
21.80
33.70
46.40
L Test
Freq.
(KHz)
100
100
100
100
100
100
100
100
100
100
100
100
Q Fact.
(Typ.)
10
20
25
32
42
46
46
55
65
65
65
65
Q Test
Freq.
(KHz)
300
300
300
300
300
300
300
300
300
300
300
300
Isat
Peak
(A)
3.4
2.1
1.7
1.4
1.1
1.0
0.8
0.68
0.54
0.45
0.37
0.31
DCR
@20°C
Ω
(Ω Max.)
0.075
0.103
0.118
0.130
0.156
0.180
0.202
0.240
0.300
0.360
0.556
0.833
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
5.88
0.231
B
Max.
7.50
0.295
C
Max.
1.8
0.071
D
Max.
5.2
0.205
CHARACTERISTICS
Description:
SMD Low Profile Power Inductors
Applications:
Wireless and hand-held equipment applications
such as PC cards, cellular telephones, pagers, GPS, and disk
drives.
Operating Temperature:
-40°C to +85°C
Storage Temperature:
-40°C to +125°C
Testing:
Inductance & Q is tested on an HP4284A at specified
frequency.
OCL Test Parameters:
100KHz, 0.25 Vrms, 0.0 Adc
Packaging:
Bulk pack
Marking:
Marked with inductance code
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PAD LAYOUT
08.29.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
