Power Inductors - Shielded
ctparts.com
CTPS1210F Series
From 1.0 µH to 22 µH
Part
Number
CTPS1210F-1R0M
CTPS1210F-1R2M
CTPS1210F-1R5M
CTPS1210F-2R2M
CTPS1210F-3R3M
CTPS1210F-4R7M
CTPS1210F-5R6M
CTPS1210F-6R8M
CTPS1210F-8R2M
CTPS1210F-100M
CTPS1210F-150M
CTPS1210F-220M
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% inductance tolerance only.
Inductance
(µH ±20%)
1.0
1.2
1.5
2.2
3.3
4.7
5.6
6.8
8.2
10
15
22
L Test
Freq.
(KHz)
100
100
100
100
100
100
100
100
100
100
100
100
DCR
±30%
Ω
(Ω)
0.050
0.055
0.070
0.090
0.160
0.200
0.210
0.250
0.330
0.350
0.600
0.890
Isat
Max.
(A)
1.30
1.20
1.00
0.80
0.70
0.58
0.55
0.50
0.43
0.40
0.30
0.25
Irms
Max.
(A)
1.90
1.70
1.40
1.35
1.00
0.90
0.85
0.80
0.70
0.65
0.55
0.40
Compliant
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
3.2±0.2
0.126±0.008
B
3.0±0.2
0.118±0.008
C
Max.
1.2
0.047
D
0.45±0.1
0.018±0.004
E
2.15±0.1
0.085±0.004
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Digital cameras, CD players, cellular phones,
PDAs, PCMCIA cards, GPS systems, etc.
Operating Temperature:
-40°C to +105°C
Inductance Tolerance:
±20%
Temp. Rise:
40°C Max.
Testing:
Tested on a HP4285A at 100 KHz, 1V
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
A
C
4R7
4R7
MARKING
(Inductance Code)
PAD LAYOUT
Unit: mm
D
D
4.2Ref.
4.0Ref.
1.8Ref.
11.06.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL
E
B
