Shielded Inductors - Axial
ctparts.com
SPECIFICATIONS
CTS1F Series
From .10 µH to 1,000 µH
Part
Number
CTS1F-R10_
CTS1F-R12_
CTS1F-R15_
CTS1F-R18_
CTS1F-R22_
CTS1F-R27_
CTS1F-R33_
CTS1F-R39_
CTS1F-R47_
CTS1F-R56_
CTS1F-R68_
CTS1F-R82_
CTS1F-1R0_
CTS1F-1R2_
CTS1F-1R5_
CTS1F-1R8_
CTS1F-2R2_
CTS1F-2R7_
CTS1F-3R3_
CTS1F-3R9_
CTS1F-4R7_
CTS1F-5R6_
CTS1F-6R8_
CTS1F-8R2_
Not shown at actual size.
Please specify tolerance code when ordering.
CTS1F-R10_
J = ±5%, K = ±10%
Inductance
(µH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
Q
Factor
Min.
39
36
35
33
35
33
33
32
33
30
30
33
35
29
29
29
28
32
32
38
38
40
46
45
45
40
45
45
45
48
54
54
54
60
55
57
60
58
60
60
60
60
60
60
60
60
60
60
60
Q Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
SRF
Min.
(MHz)
400
400
400
400
400
400
370
348
312
286
262
188
166
149
136
118
110
94
86
85
79
72
65
59
53
60
53
45.8
42.2
31.0
26.0
24.2
22.0
21.2
19.9
16.8
13.2
11.0
9.1
7.4
7.2
6.8
5.5
5.1
5.0
4.9
4.6
4.2
4.0
DCR
Max.
Ω
(Ω)
.071
.087
.109
.145
.165
.192
.228
.259
.348
.417
.580
.132
.169
.184
.26
.36
.41
.55
.62
.79
.91
1.15
1.73
1.96
2.3
.55
.71
1.0
1.09
1.35
1.9
2.1
2.4
2.9
3.2
3.7
4.6
5.2
5.9
7.4
8.5
10.0
13.4
15.0
21.0
23.0
26.0
34.0
39.0
Rated
DC
(mA)
1580
1360
1280
1110
1040
965
885
830
717
655
555
1160
1030
985
825
705
664
577
540
475
445
395
320
302
280
570
500
423
404
364
305
293
271
248
237
219
198
184
173
156
145
133
115
109
92
88
82
72
67
Compliant
RoHS
CHARACTERISTICS
Description:
Axial leaded molded (shielded) inductor
Applications:
Used for high reliability applications. Vital for
telecommunication applications. Ideal for various RF applications
Operating Temperature:
-55°C to +105°C
Inductance Tolerance:
±5% & ±10%
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Bulk pack, 1,000 parts per bag,
Tape & Reel, 5,000 parts per reel
Marking:
Parts are EIA color banded, which indicates inductance
code and tolerance
Material:
Molded epoxy resin over the magnetic core for superior
shielding and reliability
Miscellaneous:
RoHS Compliant.
Other values available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTS1F-100_
CTS1F-120_
CTS1F-150_
CTS1F-180_
CTS1F-220_
CTS1F-270_
CTS1F-330_
CTS1F-390_
CTS1F-470_
CTS1F-560_
CTS1F-680_
CTS1F-820_
CTS1F-101_
CTS1F-121_
CTS1F-151_
CTS1F-181_
CTS1F-221_
CTS1F-271_
CTS1F-331_
CTS1F-391_
CTS1F-471_
CTS1F-561_
CTS1F-681_
CTS1F-821_
CTS1F-102_
PHYSICAL DIMENSIONS
Size
mm
inches
A
6.60 ± 0.25
0.26 ± 0.010
B
2.80 ± 0.25
0.110 ± 0.010
C
Typ.
29.2
1.15
24 AWG
0.5110
0.02010
12.22.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
