Power Inductors - Shielded
ctparts.com
CTSDB1105F Series
From 10 µH to 1500 µH
Part
Number
CTSDB1105F-100M
CTSDB1105F-120M
CTSDB1105F-150M
CTSDB1105F-180M
CTSDB1105F-220M
CTSDB1105F-270M
CTSDB1105F-330M
CTSDB1105F-390M
CTSDB1105F-470M
CTSDB1105F-560M
CTSDB1105F-680M
CTSDB1105F-820M
CTSDB1105F-101M
CTSDB1105F-121M
CTSDB1105F-151M
CTSDB1105F-181M
CTSDB1105F-221M
CTSDB1105F-271M
CTSDB1105F-331M
CTSDB1105F-391M
CTSDB1105F-471M
CTSDB1105F-561M
CTSDB1105F-681M
CTSDB1105F-821M
CTSDB1105F-102M
CTSDB1105F-122M
CTSDB1105F-152M
Not shown at actual size.
SPECIFICATIONS
Parts are only available in ±20% inductance tolerance.
L Test
Freq.
(kHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
Max.
Ω
(Ω)
0.05
0.05
0.06
0.07
0.08
0.10
0.10
0.12
0.14
0.15
0.18
0.20
0.25
0.30
0.35
0.40
0.50
0.60
0.70
0.80
0.90
1.10
1.20
1.50
2.00
2.20
2.50
Rated
DC
(A)
2.50
2.40
2.30
2.20
2.10
2.00
1.90
1.80
1.60
1.40
1.30
1.20
1.10
0.97
0.86
0.84
0.72
0.65
0.61
0.58
0.50
0.48
0.43
0.38
0.35
0.32
0.30
Inductance
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
Compliant
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Switching power supplies. RFI/EMC filtering
Operating Temperature:
-25°C to +75°C
Storage Temperature:
-40°C to +125°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4284A at 1kHz
Packaging:
Tape & Reel
Marking:
Marked with inductance code
Rated DC:
Based on temperature rise &
ΔL
/ L0A = 10% typ.
Miscellaneous:
RoHS Compliant
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
12.7±0.3
0.50±0.012
B
Max.
15.0
0.59
C
5.7±0.3
0.22±0.012
D
Ref.
12.6
0.49
E
Ref.
11.6
0.47
F
3.0±0.2
0.12±0.008
G
8.2±0.3
0.32±0.012
A
D
F
XXX
E B
G
Marking:
Inductance Code
