Power Inductors - Shielded
ctparts.com
CTSLF1045 Series
From 10 µH to 1500 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTSLF1045TF
Please specify “F” for RoHS compliant.
L Test
Freq.
(kHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
±20%
Ω
(Ω)
0.0364
0.0472
0.0591
0.0815
0.1
0.14
0.2
0.35
0.47
0.68
1.03
1.6
2.8
3.4
Rated
DC
(A)
3.0
2.4
2.1
1.6
1.4
1.2
1.0
0.79
0.65
0.54
0.47
0.38
0.32
0.22
Itemp
Max.
(A)
2.5
2.2
1.9
1.7
1.5
1.3
1.1
0.81
0.7
0.58
0.47
0.38
0.29
0.26
Inductance
(µH)
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
CTSLF1045T_-100M
CTSLF1045T_-150M
CTSLF1045T_-220M
CTSLF1045T_-330M
CTSLF1045T_-470M
CTSLF1045T_-680M
CTSLF1045T_-101M
CTSLF1045T_-151M
CTSLF1045T_-221M
CTSLF1045T_-331M
CTSLF1045T_-471M
CTSLF1045T_-681M
CTSLF1045T_-102M
CTSLF1045T_-152M
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
10.1±0.3
0.40±0.012
B
10.1±0.3
0.40±0.012
C
4.5±0.3
0.18±0.012
D
Typ.
0.15
0.006
E
3±0.1
0.12±0.004
F
6±0.2
0.24±0.008
G
2±0.15
0.08±0.006
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
For power source circuits, low profile type DC to
DC converters, DC to AC inverters etc.
Operating Temperature:
-20°C to +85°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4284A at 1.0 kHz, 0.5V
IDC Current:
Value obtained when DC current flows and the
initial value of inductance has fallen by 10%
Itemp Current:
Value obtained when current flows and the
temperature has risen to 30°C
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
Magnetically shielded.
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
A
C
F
XXX
Marking
(Inductance code)
B
E
D
G
PAD LAYOUT
