Thin Film Chip Inductors
ctparts.com
SPECIFICATIONS
CTTF0201F Series
From 0.1 nH to 10 nH
Not shown at actual size.
Please specify tolerance code when ordering.
CTTF0201F-0N2_
B = ±0.1nH, C = ±0.2nH, S = ±0.3nH, G = ±2%, J = ±5%
* = G or J only
** = B, C, or S only
L Test
Freq.
(MHz)
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
Q Test
Freq.
(MHz)
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
DCR
Max.
Ω
(Ω)
0.2
0.2
0.2
0.25
0.25
0.25
0.3
0.3
0.3
0.3
0.35
0.35
0.45
0.45
0.45
0.55
0.55
0.55
0.55
0.7
0.7
0.7
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.0
1.0
1.0
1.0
1.2
1.2
1.2
1.2
1.2
1.4
1.8
2.3
3.0
3.5
Rated DC
Max.
(mA)
400
400
400
350
350
350
300
300
300
300
300
300
250
250
250
200
200
200
200
200
200
200
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
130
130
110
110
80
SRF
Min.
(GHz)
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
8
8
8
8
8
8
8
8
6
6
6
6
6
6
6
6
6
6
6
6
4
4
3
2
Part
Number
CTTF0201F-0N1_**
CTTF0201F-0N2_**
CTTF0201F-0N3_**
CTTF0201F-0N4_**
CTTF0201F-0N5_**
CTTF0201F-0N6_**
CTTF0201F-0N7_**
CTTF0201F-0N8_**
CTTF0201F-0N9_**
CTTF0201F-1N0_**
CTTF0201F-1N1_**
CTTF0201F-1N2_**
CTTF0201F-1N3_**
CTTF0201F-1N4_**
CTTF0201F-1N5_**
CTTF0201F-1N6_**
CTTF0201F-1N7_**
CTTF0201F-1N8_**
CTTF0201F-1N9_**
CTTF0201F-2N0_**
CTTF0201F-2N1_**
CTTF0201F-2N2_**
CTTF0201F-2N3_**
CTTF0201F-2N4_**
CTTF0201F-2N5_**
CTTF0201F-2N6_**
CTTF0201F-2N7_**
CTTF0201F-2N8_**
CTTF0201F-2N9_**
CTTF0201F-3N0_**
CTTF0201F-3N1_**
CTTF0201F-3N2_**
CTTF0201F-3N3_**
CTTF0201F-3N4_**
CTTF0201F-3N5_**
CTTF0201F-3N6_**
CTTF0201F-3N7_**
CTTF0201F-3N9_**
CTTF0201F-4N7_**
CTTF0201F-5N6_*
CTTF0201F-6N8_*
CTTF0201F-8N2_*
CTTF0201F-10N_*
Inductance
(nH)
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
3.0
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.9
4.7
5.6
6.8
8.2
10
Q
Min.
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Compliant
RoHS
CHARACTERISTICS
Description:
SMD thin film chip inductors
Applications:
Cellular Telephone, pagers, GPS products,
wireless LAN and other communication appliances, VCO, TCXO
circuit and RF Transceiver Module
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±0.1nH, ±0.2nH, ±0.3nH, ±2%, ±5%
Testing:
Tested on a HP4287A at 500 MHz
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
0.60 ± 0.05
0.02 ± 0.002
B
0.30 ± 0.05
0.01 ± 0.002
C
0.23 ± 0.05
0.009 ± 0.002
D
0.15 ± 0.05
0.006 ± 0.002
CONSTRUCTION
09.12.08
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
TECHNOLOGIES
