INCHANGE Semiconductor
isc
Silicon NPN Darlington Power Transistor
DESCRIPTION
·With
TO-251(IPAK) packaging
·Very
high DC current gain
·Monolithic
darlington transistor with integrated
antiparallel collector-emitter diode
·Complement
to type 2SB963
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·AC-DC
motor control
·Electronic
ignition
·Alternator
regulator
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
P
T
T
j
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Total Power Dissipation
Max.Junction Temperature
Storage Temperature Range
VALUE
60
60
8
1
2
10
150
-55~150
UNIT
V
V
V
A
A
W
℃
℃
2SD1286
THERMAL CHARACTERISTICS
SYMBOL
R
th j-a
PARAMETER
Thermal Resistance,Junction to Ambient
MAX
62.5
UNIT
℃/W
isc website：
www.iscsemi.com
1
isc
&
iscsemi
is registered trademark
INCHANGE Semiconductor
isc
Silicon NPN Darlington Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
CEO(SUS)
V
CE(sat)
V
BE(sat)1
I
CBO
I
EBO
h
FE-1
h
FE-2
PARAMETER
Collector-Emitter Sustaining Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
CONDITIONS
I
C
= 1mA, I
B
= 0
I
C
=0.5A ,I
B
= 50mA
I
C
=0.5A ,I
B
= 50mA
V
CB
=60V, I
E
= 0
V
EB
= 5V; I
C
= 0
I
C
= 0.2A ; V
CE
= 2V
I
C
= 0.5A ; V
CE
= 2V
1000
6000
MIN
60
2SD1286
MAX
UNIT
V
1.5
2.0
10
10
-
30000
V
V
μA
μA
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
2
isc website：
www.iscsemi.com
isc
&
iscsemi
is registered trademark
