Fast Recovery Rectifier
FEATURES
·High
Performance Fast Recovery Diode
·Low
Loss and Soft Recovery
·Single
Diode
·Very
low leakage current
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Antiparallel
diode for high frequency switching devices
·Anti-saturation
diode
·Snubber
diode
·Free
wheeling diode in converters and motor control circuits
DPG15I400PM
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
RRM
V
RWM
V
R
I
F(AV)
PARAMETER
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
Non-repetitive Peak Surge Current@45℃
(Surge applied at rated load conditions half-
wave, single phase, 60Hz)
Junction Temperature
VALUE
UNIT
1m
400
V
15
A
I
FSM
190
A
T
J
-40~150
℃
T
stg
Storage Temperature Range
-40~150
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
Fast Recovery Rectifier
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
PARAMETER
Thermal Resistance,Junction to Case
DPG15I400PM
MAX
4.2
UNIT
℃/W
ELECTRICAL CHARACTERISTICS
(T
a
=25℃)
(Pulse Test: Pulse Width=300μs,Duty Cycle≤2%)
SYMBOL
PARAMETER
CONDITIONS
I
F
=15A ;T
J
=25℃
I
F
=15A ;T
J
=150℃
I
F
=30A ;T
J
=25℃
I
F
=30A ;T
J
=125℃
V
R
= 400V ;T
J
=25℃
I
R*
Maximum Instantaneous Reverse Current
V
R
= 400V;T
J
=150℃
Maximum Reverse Recovery Time
IF =15A;di/dt = 200A/µs
180
45
μA
ns
MAX
1.39
1.14
1.63
1.4
1
UNIT
V
V
V
V
μA
V
F*
Maximum Instantaneous Forward Voltage
t
rr
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not
designed for use in equipment which require specialized quality and/or reliability, or in equipment
which could have applications in hazardous environments, aerospace industry, or medical
field. Please contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
isc website
：
www.iscsemi.com
2
isc & iscsemi
is registered trademark
