Common Mode Chokes - Radial
ctparts.com
CTUF1015VF Series
From 0.6 mH to 10 mH
Not shown at actual size.
SPECIFICATIONS
Part
Number
* Indicates the inductance difference between the coil L1 and L2.
Inductance
Inductance
DCR
Rated Current
(Min.)
Difference*
(Max.)
(Max.)
Ω
(mH)
(µH Max.)
(Ω)
(A)
10
5
3
2
1
1
0.8
0.6
0.6
0.6
300
200
60
100
100
50
50
50
50
50
2.0
1.2
0.5
0.4
0.4
0.17
0.12
0.2
0.09
0.07
0.3
0.5
0.9
1.0
1.0
1.6
1.5
1.3
2.0
2.5
CTUF1015VF-103M0R3
CTUF1015VF-502M0R5
CTUF1015VF-302M0R9
CTUF1015VF-202M1R0
CTUF1015VF-102M1R0
CTUF1015VF-102M1R6
CTUF1015VF-801M1R5
CTUF1015VF-601M1R3
CTUF1015VF-601M2R0
CTUF1015VF-601M2R5
Compliant
RoHS
PHYSICAL DIMENSIONS
CHARACTERISTICS
Description:
Common mode choke coils.
Applications:
For power supply line.
Rated Voltage:
250Vac
Operating Temperature Range:
-20°C to +105°C including self
temperature rise.
Temperature Rise:
45°C maximum each line.
Dielectric Withstanding Voltage:
2000Vac between each
winding for 1 minute.
Insulation Resistance:
100MΩ minimum between each winding
for 1 minute.
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request. Different inductance and
current products are available as well.
Samples available. See website for ordering information.
