Power Inductors - Unshielded
ctparts.com
CTUP3B Series
From 0.47 µH to 100 µH
Part
Number
CTUP3B_-0R47
CTUP3B_-1R0
CTUP3B_-1R5
CTUP3B_-2R2
CTUP3B_-2R8
CTUP3B_-4R7
CTUP3B_-6R8
CTUP3B_-100
CTUP3B_-150
CTUP3B_-220
CTUP3B_-330
CTUP3B_-470
CTUP3B_-680
CTUP3B_-101
Not shown at actual size.
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTUP3BF
Please specify “F” for RoHS Compliant
Inductance
(µH)
.47
1.0
1.5
2.2
2.8
4.7
6.8
10
15
22
33
47
68
100
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
2.50
4.30
5.90
7.50
10.3
15.0
22.0
27.0
45.0
63.0
102.0
132.0
185.0
265.0
Rated DC
Current
(A)
25.1
15.3
12.0
10.2
9.30
7.70
6.20
5.20
4.30
3.70
3.00
2.40
2.00
1.80
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
13.3
0.524
12.7
0.500
B
C
Max.
6.9
0.272
D
Max.
19.5
0.768
CHARACTERISTICS
Description:
SMD power inductor
Applications:
DC/DC converters, computers, LCD displays,
telecommunication equipment and PDA palm tops.
Operating Temperature:
-30°C to +100°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Inductance code
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
XXX
A
Marking
(Inductance Code)
C
PAD LAYOUT
Unit: mm
B
4.0
13.0
7.85
D
02.11.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
