CWD4825EH datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> CWD4825EH

CWD4825EH: DescriptionTRIGGER OUTPUT SOLID STATE RELAY, 4000 V ISOLATION-MAX; CategoryLED optoelectronic/LED photoelectric; File Size596KB，5 Pages; ManufacturerCrydom; Websitehttp://www.crydom.com/en/index.shtml

Download Datasheet Parametric View All

CWD4825EH Overview

TRIGGER OUTPUT SOLID STATE RELAY, 4000 V ISOLATION-MAX

CWD4825EH Parametric

Parameter Name	Attribute value
Maker	Crydom
Reach Compliance Code	compliant
Base Number Matches	1

Preview

Download Datasheet

View All

CW48 Series

• The newest family to the SSR range; Ratings from 10A to 125A @

12-660 VAC

• SCR output for heavy industrial loads

• EMC Compliant for reliable operation in harsh environments

• Removable IP 20 touch-safe cover

• DBC substrate for superior therm al performance

• LED input status indicator

• AC or DC input

PRODUCT SELECTION

Description

3-32 VDC

90-280 Vrms

18-36 Vrms

10A

CWD4810

CWA4810

CWA4810E

25A

CWD4825

CWA4825

CWA4825E

50A

CWD4850

CWA4850

CWA4850E

90A

CWD4890

CWA4890

CWA4890E

125A

CWD48125

CWA48125

CWA48125E

AVAILABLE OPTIONS

OUTPUT SPECIFICATIONS (1)

Description

Operating Voltage (47-63Hz) [Vrms] (8)

Transient Overvoltage [Vpk]

Maximum Off-State Leakage Current @ Rated Voltage [mArms](6)

Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec] (2)

Maximum Load Current (3) [Arms]

Minimum Load Current [Arms]

Maximum Surge Current (16.6ms) [Apk]

Maximum Surge Current (20ms) [Apk]

Maximum On-State Voltage Drop @ Rated Current [Vpk]

Thermal Resistance Junction to Case (Rjc) [°C/W]

Maximum I²t for Fusing (8.3 msec) [A²sec]

Minimum Power Factor (with Maximum Load)

10A

48-660

1200

1.0

500

0.15

400

380

1.3

0.35

660

0.5

25A

48-660

1200

1.0

500

0.15

600

570

1.3

0.35

1500

0.5

50A

48-660

1200

1.0

500

0.15

850

810

1.3

0.2

3000

0.5

90A

48-660

1200

1.0

500

0.25

1350

1290

1.3

0.14

7560

0.5

125A

48-660

1200

1.0

500

125

0.25

2000

1900

1.25

0.13

16600

0.5
