Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Mechanical Data
Case: SOT-523
Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish Annealed over Alloy 42 Leadframe
(Lead-Free Plating); Solderable per MIL-STD-202, Method 208
Polarity: See Diagrams Below
Weight: 0.002 grams (Approximate)
SOT-523
TOP VIEW
BAS16T Marking: A2
BAW56T Marking: JD
BAV70T Marking: JJ
BAV99T Marking: JE
Ordering Information
(Note 5)
Part Number
BAS16T-7-F
BAW56T-7-F
BAV70T-7-F
BAV99T-7-F
BAV99TQ-13-F
Notes:
Compliance
Standard
Standard
Standard
Standard
Automotive
Case
SOT-523
SOT-523
SOT-523
SOT-523
SOT-523
Packaging
3,000/Tape & Reel
3,000/Tape & Reel
3,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
SOT-523
XX = Product Type Marking Code (See this page, e.g. A2 = BAS16T)
Reverse recovery time (trr): 4ns DC reverse withstand voltage (Vr): 85V Average rectified current (Io): 75mA Forward voltage drop (Vf): 1V @ 50mA 85V, 75mA, VF=1.25V@150mA
