3.3 V power supply. All supply current flows through pin 1
Document #: 001-48923 Rev. *C
Page 3 of 10
[+] Feedback
CY2XP41
Frequency Table
Input
Input Xtal Frequency (MHz)
25
25
FS
0
1
Output Frequency (MHz)
62.5
75.0
Absolute Maximum Conditions
Parameter
V
DD
V
IN[1.]
T
S
T
J
ESD
HBM
UL–94
Θ
JA[2]
Description
Supply Voltage
Input Voltage, DC
Temperature, Storage
Temperature, Junction
ESD Protection (Human Body Model) JEDEC STD 22-A114-B
Flammability Rating
Thermal Resistance, Junction to
Ambient
At 1/8 in.
0 m/s airflow
1 m/s airflow
2.5 m/s airflow
Relative to VSS
Non Functional
Condition
Min
–0.5
–0.5
–65
–
2000
V–0
100
91
87
°C/W
Max
4.4
V
DD
+ 0.5
150
135
–
Unit
V
V
°C
°C
V
Operating Conditions
Parameter
V
DD
T
A
T
PU
3.3 V Supply Voltage
Ambient Temperature, Commercial
Power up time for all V
DD
to reach minimum specified voltage (ensure power
ramps are monotonic)
Description
Min
3.135
0
0.05
Max
3.465
70
500
Unit
V
°C
ms
Electrical Characteristics for Input
Parameter
V
IL
V
IH
I
IL
I
IH
C
IN[3]
C
INX[3]
Description
Input Low Voltage , FS
Input High Voltage, FS
Input Low Current , FS
Input High Current, FS
Input Capacitance, FS
Input Capacitance, XIN & XOUT
FS = V
SS
FS = V
DD
Test Conditions
Min
–
0.7*V
DD
–50
–
–
–
Typ
–
–
–
–
15
4.5
Max
0.3*V
DD
–
–
115
–
–
Unit
V
V
µA
µA
pF
pF
DC Electrical Characteristics for Power Supplies
Parameter
I
DD
I
DDT
Description
Power Supply Current with output unterminated
Power Supply Current with output terminated
Min
–
–
Typ
–
–
Max
125
180
Unit
mA
mA
Note
1. The voltage on any input or IO pin cannot exceed the power pin during power up. Power supply sequencing is NOT required.
2. Simulated using Apache Sentinel TI software. The board is derived from the JEDEC multilayer standard. It measures 76 x 114 x 1.6 mm and has 4-layers of
copper (2/1/1/2 oz.). The internal layers are 100% copper planes, while the top and bottom layers have 50% metallization. No vias are included in the model.
3. Not 100% tested, guaranteed by design and characterization.
