34708-4070 datasheet, PDF - EEWORLD Datasheet

34708-4070: DescriptionStac64 4 Bay Right Angle Headers, 68 Circuits, Bay A 20 Circuit Signal Header; File Size55KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet View All

34708-4070 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	34708-4070	-	-	View	Buy Now

34708-4070 Overview

Stac64 4 Bay Right Angle Headers, 68 Circuits, Bay A 20 Circuit Signal Header

Preview

Download Datasheet

View All

This document was generated on 07/09/2014

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

34708-4070

Active

Stac64™ Single, Multi-Pocket and Hybrid Header System

Stac64™ 4 Bay Right Angle Headers, 72 Circuits, Bay A 12 Circuit Signal Header,

Polarization A, Black; Bay B 20 Circuit Signal Header, Polarization D, Green; Bay C 20

Circuit Signal Header, Polarization C, Brown; Bay D 20 Circuits Stac64™ Right Angle

Signal, Polarization A, Tray

Documents:

3D Model

Drawing (PDF)

Application Specification AS-34729-020 (PDF)

RoHS Certificate of Compliance (PDF)

Product Literature (PDF)

Series

image - Reference only

EU RoHS

ELV and RoHS

Compliant

REACH SVHC

Contains SVHC: No

Low-Halogen Status

Low-Halogen

China RoHS

General

Product Family

Series

Application

Comments

PCB Headers

34708

Power, Wire-to-Board

Bay A 12 Circuits Stac64™ Right Angle Signal Header,

Polarization A. Bay B 20 Circuits Stac64™ Right

Angle Signal Header, Polarization D. Bay C 20 Circuits

Stac64™ Right Angle Signal Header, Polarization

C. Bay D 20 Circuits Stac64™ Right Angle Signal,

Polarization A

Stac64™ Single, Multi-Pocket and Hybrid Header

System

987650-4561

Stac64™

884982416697

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Overview

Product Literature Order No

Product Name

UPC

Physical

Breakaway

Circuits (Loaded)

Circuits (maximum)

Color - Resin

Durability (mating cycles max)

First Mate / Last Break

Glow-Wire Compliant

Guide to Mating Part

Keying to Mating Part

Lock to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Net Weight

Number of Rows

Orientation

PC Tail Length

PCB Locator

PCB Retention

PCB Thickness - Recommended

Packaging Type

Pitch - Mating Interface

Pitch - Termination Interface

Polarized to Mating Part

Polarized to PCB

Black, Brown, Green

None

Yes

Copper Alloy

Nickel

Tin

High Temperature Thermoplastic

32.065/g

Right Angle

3.36mm

Yes

None

1.57mm

Tray

2.54mm

Yes

Search Parts in this Series

34708Series

Mates With

31408 USCAR 2.54mm (.100”) Pitch

Receptacle, 31372 5.25mm (.206") Pitch

Hybrid Receptacle Assembly, 34729

2.54mm (.100") Pitch Stac64™ Right Angle

Receptacle
