LTC2246CUH#TR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> LTC2246CUH#TR

LTC2246CUH#TR: DescriptionIC 1-CH 14-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PQCC32, 5 X 5 MM, PLASTIC, MO-220WHHD-X, QFN-32, Analog to Digital Converter; CategoryAnalog mixed-signal IC converter; File Size743KB，24 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric Compare View All

LTC2246CUH#TR Overview

IC 1-CH 14-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PQCC32, 5 X 5 MM, PLASTIC, MO-220WHHD-X, QFN-32, Analog to Digital Converter

LTC2246CUH#TR Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Linear ( ADI )
Parts packaging code	QFN
package instruction	HVQCCN, LCC32,.2SQ,20
Contacts	32
Reach Compliance Code	_compli
ECCN code	3A991.C.3
Maximum analog input voltage	1.9 V
Minimum analog input voltage	1 V
Converter type	ADC, PROPRIETARY METHOD
JESD-30 code	S-PQCC-N32
JESD-609 code	e0
length	5 mm
Maximum linear error (EL)	0.0244%
Humidity sensitivity level	1
Number of analog input channels	1
Number of digits	14
Number of functions	1
Number of terminals	32
Maximum operating temperature	70 °C
Minimum operating temperature
Output bit code	OFFSET BINARY, 2\'S COMPLEMENT BINARY
Output format	PARALLEL, WORD
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Encapsulate equivalent code	LCC32,.2SQ,20
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	235
power supply	3 V
Certification status	Not Qualified
Sampling rate	25 MHz
Sample and hold/Track and hold	SAMPLE
Maximum seat height	0.8 mm
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	20
width	5 mm

Preview

Download Datasheet

View All

LTC2248/LTC2247/LTC2246

14-Bit, 65/40/25Msps

Low Power 3V ADCs

FEATURES

■

DESCRIPTIO

■

Sample Rate: 65Msps/40Msps/25Msps

Single 3V Supply (2.7V to 3.4V)

Low Power: 205mW/120mW/75mW

74.3dB SNR

90dB SFDR

No Missing Codes

Flexible Input: 1V

P-P

to 2V

P-P

Range

575MHz Full Power Bandwidth S/H

Clock Duty Cycle Stabilizer

Shutdown and Nap Modes

Pin Compatible Family

125Msps: LTC2253 (12-Bit), LTC2255 (14-Bit)

105Msps: LTC2252 (12-Bit), LTC2254 (14-Bit)

80Msps: LTC2229 (12-Bit), LTC2249 (14-Bit)

65Msps: LTC2228 (12-Bit), LTC2248 (14-Bit)

40Msps: LTC2227 (12-Bit), LTC2247 (14-Bit)

25Msps: LTC2226 (12-Bit), LTC2246 (14-Bit)

10Msps: LTC2225 (12-Bit), LTC2245 (14-Bit)

32-Pin (5mm

5mm) QFN Package

The LTC

2248/LTC2247/LTC2246 are 14-bit 65Msps/

40Msps/25Msps, low power 3V A/D converters designed

for digitizing high frequency, wide dynamic range signals.

The LTC2248/LTC2247/LTC2246 are perfect for demand-

ing imaging and communications applications with AC

performance that includes 74.3dB SNR and 90dB SFDR

for signals at the Nyquist frequency.

DC specs include

±1LSB

INL (typ),

±0.5LSB

DNL (typ) and

no missing codes over temperature. The transition noise

is a low 1LSB

RMS

A single 3V supply allows low power operation. A separate

output supply allows the outputs to drive 0.5V to 3.6V

logic.

A single-ended CLK input controls converter operation. An

optional clock duty cycle stabilizer allows high perfor-

mance at full speed for a wide range of clock duty cycles.

, LTC and LT are registered trademarks of Linear Technology Corporation.

All other trademarks are the property of their respective owners.

APPLICATIO S

■

Wireless and Wired Broadband Communication

Imaging Systems

Ultrasound

Spectral Analysis

Portable Instrumentation

TYPICAL APPLICATIO

REFH

REFL

FLEXIBLE

REFERENCE

ANALOG

INPUT

S/H

SNR (dBFS)

–

14-BIT

PIPELINED

ADC CORE

CORRECTION

LOGIC

OUTPUT

DRIVERS

D13

•

OGND

CLOCK/DUTY

CYCLE

CONTROL

2249 TA01a

CLK

LTC2248: SNR vs Input Frequency,

–1dB, 2V Range, 65Msps

100

150

INPUT FREQUENCY (MHZ)

200

2249 TAO1b

224876fa
