Table 1 . Product performance of LUXEON FlipChip White at test current, T
j
=85ºC .
LUMINOUS FLUX
[1]
(lm)
PRODUCT
NOMINAL
CCT
4000K
2700K
3000K
4000K
LUXEON
FlipChip
White
10
5000K
5700K
2700K
3000K
4000K
MINIMUM
CRI
[1, 2]
70
80
80
70
70
70
80
80
80
MINIMUM
TYPICAL
TEST CURRENT
LUXEON
FlipChip
White
05
57
45
47
120
120
120
90
100
104
60
49
53
135
137
137
108
114
121
124
101
109
139
141
141
111
118
124
TYPICAL
LUMINOUS
EFFICACY
(lm/W)
TYPICAL
LUMINOUS
FLUX (lm)
TYPICAL
LUMINOUS
TEST
EFFICACY CURRENT
(lm/W)
(mA)
2X TEST CURRENT
106
86
94
238
242
242
189
200
212
105
86
94
118
120
120
94
99
106
175
175
175
350
350
350
350
350
350
PART NUMBER
LxF2-4070050000000
LxF2-2780050000000
LxF2-3080050000000
LxF2-4070100000000
LxF2-5070100000000
LxF2-5770100000000
LxF2-2780100000000
LxF2-3080100000000
LxF2-4080100000000
Notes for Table 1:
1. Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2. Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
Optical Characteristics
Table 2 . Optical characteristics for LUXEON FlipChip White at test current, T
j
=85°C .
PART NUMBER
LxF2-xxxxxx0000000
TYPICAL TOTAL INCLUDED ANGLE
[1]
168°
TYPICAL VIEWING ANGLE
[2, 3]
148°
Notes for Table 2:
1. Total angle at which 90% of total luminous flux is captured.
2. Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value. Radiation pattern slice measured in the plane parallel to one of the four sides of
the emitter.
3. Represents optical characteristics when mounted on a silver reflective substrate.
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON FlipChip White at test current, T
j
=85ºC .
PART NUMBER
LxF2-xxxx050000000
LxF2-xxxx100000000
FORWARD VOLTAGE (V)
[1]
MINIMUM
2.50
2.50
TYPICAL
2.77
2.77
MAXIMUM
3.10
3.10
TYPICAL TEMPERATURE
COEFFICIENT OF FORWARD
VOLTAGE (mV/°C)
[2]
-1.9
-1.9
TYPICAL THERMAL
RESISTANCE — JUNCTION TO
SOLDER PAD (°C/W)
4
2
Notes for Table 3:
1. Lumileds maintains a tolerance of ±0.06V on forward voltage measurements.
Table 4 . Absolute maximum ratings for LUXEON FlipChip White .
PARAMETER
LED Junction Temperature
[1]
(DC & Pulse)
DC Forward Current
[1,2]
Peak Pulsed Forward Current
[1,3]
Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
[4]
Reverse Voltage (V
reverse
)
MAXIMUM PERFORMANCE
LUXEON FLIPCHIP WHITE 05
150°C
350
420
135°C
525
600
-40°C to 135°C
260°C
3
LUXEON LEDs are not designed to be driven in reverse bias
LUXEON FLIPCHIP WHITE 10
150°C
700
840
135°C
1050
1200
Notes for Table 4:
1. Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is ≥100 Hz and amplitude ≤15% of the maximum DC current are acceptable
– The average current for each cycle does not exceed the maximum allowable DC forward current at the corresponding maximum junction temperature
– The maximum amplitude of the ripple does not exceed the maximum peak pulsed forward current
3. Pulsed operation with a peak drive current equal to the stated Peak Pulsed Forward Current is acceptable if the pulse on-time is ≤ 5 ms per cycle and the duty cycle is ≤ 50%.
