BAS70-06S

Description
0.07 A, 4 ELEMENT, SILICON, SIGNAL DIODE
CategoryDiscrete semiconductor    diode
File Size46KB,4 Pages
ManufacturerSIEMENS
Websitehttp://www.infineon.com/
Download Datasheet Parametric Compare View All

BAS70-06S Overview

0.07 A, 4 ELEMENT, SILICON, SIGNAL DIODE

BAS70-06S Parametric

Parameter NameAttribute value
MakerSIEMENS
Reach Compliance Codeunknow
ECCN codeEAR99
Configuration2 BANKS, COMMON ANODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JESD-30 codeR-PDSO-G6
Number of components4
Number of terminals6
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current0.0175 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Maximum power dissipation0.25 W
Certification statusNot Qualified
Maximum repetitive peak reverse voltage70 V
surface mountYES
technologySCHOTTKY
Terminal formGULL WING
Terminal locationDUAL
BAS 70-06S
Silicon Schottky Diode Array
General-purpose diode for high-speed switching
Circuit protection
Voltage clamping
High-level detecting and mixing
Available with CECC quality assessment
4
5
6
2
1
3
VPS05604
Type
BAS 70-06S
Marking Ordering Code
76s
Q62702-A3469
Pin Configuration
1/4=C1
2/5=C2
Package
3/6=A1/A2SOT-363
Maximum Ratings
Parameter
Diode reverse voltage
Forward current
Surge forward current (t< 100µs)
Total power dissipation,
T
S
72 °C
Junction temperature
Operating temperature range
Storage temperature
Thermal Resistance
Junction - ambient
1)
Symbol
Value
70
70
100
250
150
- 55 ...+150
- 55 ...+150
Unit
V
mA
mW
°C
V
R
I
F
I
FSM
P
tot
T
j
T
op
T
stg
R
thJA
R
thJS
545
310
K/W
Junction - soldering point
1) Package mounted on epoxy pcb 40mm x 40mm x 1.5mm / 0.5cm 2 Cu
Semiconductor Group
Semiconductor Group
1
1
Sep-07-1998
1998-11-01
