D Series
Vishay BCcomponents
Ceramic Disc Capacitors
Class 1 and 2, 500 V
DC
, General Purpose
D
D
FEATURES
• Low losses
• High stability
• High capacitance in small size
SH
Tangent
line
SH
Tangent
line
• Kinked (preferred) or straight leads
• Compliant to RoHS directive 2002/95/EC
APPLICATIONS
• Bypassing
F
F
• Coupling
• Resonant circuit
Capacitors with 5 mm (0.20"
)
and 7.5 mm (0.30"
)
lead spacing
QUICK REFERENCE DATA
DESCRIPTION
Voltage (V
DC
)
Min. Capacitance (pF)
Max. Capacitance (pF)
Mounting
10
82
CLASS 1
(C0G (NP0),
SL0)
CLASS 2
(YP5, Z5U, Y5V, X5F)
500
100
22 000
Through hole
DESIGN
The capacitors consist of a ceramic disc both sides of which
are silver-plated. Connection leads are made of tinned
copper having a diameter of 0.6 mm.
The capacitors have inward kinked leads with a spacing of
5 mm (0.200") or 7.5 mm (0.300") and a lead length from
4 mm to 30 mm. Encapsulation is made of phenolic resin.
CAPACITANCE RANGE
Class 1, at 1 MHz, 1.2 V
RMS
; 10 pF to 82 pF
Class 2, at 1 kHz, 1 ± 0.2 V
RMS
; 100 pF to 22 000 pF
1 kHz, 1 V
RMS
± 0.2 V
RMS
for capacitance values higher than
1000 pF
MARKING
Marking indicates capacitance value and tolerance in
accordance with “EIA 198”.
The capacitors meet the essential requirements of
“EIA 198”. Unless stated otherwise all electrical values apply
at an ambient temperature of 25 °C ± 3 °C, at normal
atmospheric conditions.
RATED DC VOLTAGE
500 V
OPERATING TEMPERATURE RANGE
Class 1, - 55 °C to + 125 °C
Class 2, - 55 °C to + 85 °C
DIELECTRIC STRENGTH
250 % of rated voltage
INSULATION RESISTANCE AT 500 V
DC
≥
10 000 MΩ
TEMPERATURE COEFFICIENTS
Class 1, C0G (NP0); SL0
Class 2, Y5P; Z5U; Y5V; X5F
TOLERANCE ON CAPACITANCE
± 5 %; ± 10 %; ± 20 %; + 80/- 20 %
SECTIONAL SPECIFICATIONS
Class 1, IEC 60 384-8
Class 2, IEC 60 384-9
EIA 198
DISSIPATION FACTOR
Class 1, C
≤
30 pF;
≤
20 x (10/C + 0.7) x 10
-4
maximum
Class 1, C > 30 pF;
≤
0.2 %
Class 2,
≤
3.0 %
CLIMATIC CATEGORY
Class 1, 55/125/21
Class 2, 10/85/21, 30/85/21 and 55/85/21
www.vishay.com
40
For technical questions, contact:
CDC@vishay.com
Document Number: 28513
Revision: 07-Jan-10
D Series
Ceramic Disc Capacitors
Class 1 and 2, 500 V
DC
, General Purpose
Vishay BCcomponents
ORDERING INFORMATION (PREFERED TYPES), CLASS 1, 500 V
DC
, KINKED
CLEAR TEXT CODE
C
(pF)
TOL.
(%)
D
MAX.
(mm)
LEAD SPACING
(mm)
SH
(1)
(mm)
13
TH
DIGIT:
T = REEL; U = AMMO; 3 = BULK
16
TH
DIGIT:
R = RoHS COMPLIANT
D100J20C0GL6.J5.
D120J20C0GL6.J5.
D150J20C0GL6.J5.
D180J25C0GL6.J5.
D220J25C0GL6.J5.
D270J25C0GL6.J5.
D330J20SL0L6.J5.
D390J20SL0L6.J5.
D470J20SL0L6.J5.
D560J20SL0L6.J5.
D680J25SL0L6.J5.
D820J25SL0L6.J5.
CLASS 1 NP0
10
12
15
18
22
27
CLASS 1 SL0
33
39
47
56
68
82
5.0
±5
6.5
5.0
4.0
5.0
±5
6.5
5.0
4.0
Notes
(1)
SH = seated height
• Maximum thickness 4.0 mm
• Lead style codes refer to inward kinked leads. Other styles available on request
ORDERING INFORMATION (PREFERED TYPES), CLASS 2, 500 V
DC
, KINKED
CLEAR TEXT CODE
C
(pF)
TOL.
(%)
D
MAX.
(mm)
LEAD SPACING
(mm)
SH
(1)
(mm)
13
TH
DIGIT:
T = REEL; U = AMMO; 3 = BULK
16
TH
DIGIT:
R = RoHS COMPLIANT
D101K20Y5PL6.J5.
D151K20Y5PL6.J5.
D221K20Y5PL6.J5.
D331K20Y5PL6.J5.
D471K20Y5PL6.J5.
D681K25Y5PL6.J5.
D102K25Y5PL6.J5.
D152K29Y5PL6.J5.
D222K33Y5PL6.J5.
D332K39Y5PL6.J5.
D472K43Y5PL6.J5.
D682K53Y5PL6.J7
D103K69Y5PL6.J7.
D102Z20Y5VL6.J5.
D152Z20Y5VL6.J5.
D222Z25Y5VL6.J5.
D322Z25Y5VL6.J5.
D472Z29Y5VL6.J5.
D682Z33Y5VL6.J5.
D103Z39Y5VL6.J5.
D153Z43Y5VL6.J5.
D223Z53Y5VL6.J7.
www.vishay.com
41
CLASS 2 Y5P
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10 000
CLASS 2 Y5V
1000
1500
2200
3300
4700
6800
10 000
15 000
22 000
5
± 10
6.5
7.5
8.5
10
11
13.5
17.5
5
4.0
7.5
5
6.5
+ 80/- 20
7.5
8.5
10.0
11.0
13.5
5
4.0
7.5
Document Number: 28513
Revision: 07-Jan-10
For technical questions, contact:
CDC@vishay.com
D Series
Vishay BCcomponents
Ceramic Disc Capacitors
Class 1 and 2, 500 V
DC
, General Purpose
ORDERING INFORMATION (PREFERED TYPES), CLASS 2, 500 V
DC
, KINKED
CLEAR TEXT CODE
C
(pF)
TOL.
(%)
D
MAX.
(mm)
LEAD SPACING
(mm)
SH
(1)
(mm)
13
TH
DIGIT:
T = REEL; U = AMMO; 3 = BULK
16
TH
DIGIT:
R = RoHS COMPLIANT
D102M20Z5UL6.J5.
5.0
7.5
± 20
8.5
10.0
11.0
13.5
15.0
7.5
5.0
4.0
D152M25Z5UL6.J5.
D222M25Z5UL6.J5.
D332M29Z5UL6.J5.
D472M33Z5UL6.J5.
D682M39Z5UL6.J5.
D103M43Z5UL6.J5.
D153M53Z5UL6.J7.
D223M59Z5UL6.J7.
D101K20X5FL6.J5.R.
5.0
5.0
D221K20X5FL6.J5.R.
D331K20X5FL6.J5.R.
± 10
6.5
7.5
10.0
12.0
13.5
7.5
4.8
4.0
D471K25X5FL6.J5.R.
D681K25X5FL6.J5.R.
D102K29X5FL6.J5.R.
D222K39X5FL6.J5.R.
D332K47X5FL6.J7R.
D472K53X5FL6.J7R.
CLASS 2 Z5U
1000
1500
2200
3300
4700
6800
10 000
15 000
22 000
CLASS 2 X5F
1 00
2 20
330
470
680
1000
2200
3300
4700
Note
(1)
SH = seated height
• Maximum thickness 4.0 mm
• Lead style codes refer to inward kinked leads. Other styles available on request
PACKAGING
D
MAX.
(mm)
5.0 (0.20")
6.5 (0.25")
7.5 (0.29")
8.5 (0.33")
10.0 (0.39")
11.0 (0.43")
12.0 (0.47")
13.5 (0.53")
15.0 (0.59")
17.5 (0.69")
SIZE CODE
20
25
29
33
39
43
47
53
59
69
500
-
-
1000
2000
2000
PACKAGING QUANTITIES
BULK
REEL
AMMO
Note
• The capacitors are supplied in bulk packaging (cardboard boxes), in tape on reel or in ammopack.
www.vishay.com
42
For technical questions, contact:
CDC@vishay.com
Document Number: 28513
Revision: 07-Jan-10
D Series
Ceramic Disc Capacitors
Class 1 and 2, 500 V
DC
, General Purpose
D
P
2
P
ΔP
ΔP
Vishay BCcomponents
Δh
Δh
H
1
W
2
H
0
W
1
W
0
W
A
e
P
1
Direction of unreeling
Ød
F
P
0
D
0
t
1
Kinked capacitors on tape, lead
spacing
5.0 mm (0.2")
detail A
DIMENSIONS OF TAPE
SYMBOL
D
d
P
(1)
P
0
ΔP
P
1 (2)
P
2 (2)
F
Δh
W
W
0
W
1
W
2
H
0
H
1
e
L
D
0
t
t
1
PARAMETER
Body diameter
Lead diameter
Pitch between capacitors
Feed-hole pitch
Plane deviation
Feed-hole center to lead center
Feed-hole center to component center
Lead spacing
Component alignment
Tape width
Hold-down tape width
Hole position
Hold-down tape margin
Height to seating plane
Maximum component height
Lead end protrusion
Maximum length of snipped lead
Feed-hole diameter
Total tape thickness
Maximum thickness of tape and wires
DIMENSIONS (mm)
NOMINAL
11.0 maximum
0.6
12.7
12.7
1.0 maximum
3.85
6.35
5.0
0
18.0
5.0 minimum
9.0
3.0 maximum
16.0
32.0
1.0 maximum
11.0
4.0
0.9 maximum
1.5 maximum
TOLERANCE
-
± 0.05
± 1.0
± 0.3
-
± 0.7
± 1.3
0.6
- 0.4
± 1.0
1.0
- 0.5
-
0.75
- 0.5
-
± 0.5
-
-
-
± 0.2
-
-
Notes
(1)
Cumulative pitch error: ±
≤
1 mm/20 pitches
(2)
Obliquity maximum 3°
Document Number: 28513
Revision: 07-Jan-10
For technical questions, contact:
CDC@vishay.com
www.vishay.com
43
