Coaxial
50Ω
Features
•
•
•
•
•
•
•
•
High Power Amplifier
100W
50 to 500 MHz
High power, 100 Watt
Excellent IP3, +57 dBm typ.
Class A amplifier, usable up to 100W.
No damage with an open or short output load under full CW output power
1
Shuts off when base plate temperature exceeds +100°C
Internal power regulator (current remains constant over 22 to 28V)
Over voltage protection, shut off above 29V
Protected by US Patent 7,348,854
ZHL-100W-52+
Applications
•
•
•
•
Model No.
Case Style
Connectors
Price (Qty.)
ZHL-100W-52-S+
ZHL-100W-52X-S+
L
BT1165
SMA
$1995.00 ea. (1-9)
$1920.00 ea. (1-9)
VHF/UHF transmitters
Defense
Amateur radio, FM, TV
Laboratory use
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications at 25°C
ZHL-100W-52+
Parameter
Frequency Range
Gain
Gain Flatness
Output Power at 1dB compression
Saturated Output Power at 3dB compression
Noise Figure
Output third order intercept point
Input VSWR
Output VSWR
DC Supply Voltage
Supply Current
1. At constant open or short load 24V nominal supply voltage
ZHL-100W-52X+
L
Max.
500
Condition (MHz)
Min.
50
47
Typ.
50
±1.2
+48
+47
+49
+48.5
4.5
+57
1.45
2.5
24
Min
50
47
+46.5
+45
+47.5
+46.5
Typ.
50
±1.2
+48
+47
+49
+48.5
4.5
+57
1.45
2.5
24
Max.
500
±1.8
Units
MHz
dB
dB
dBm
dBm
±1.8
200-300
50-500
200-300
50-500
+46.5
+45
+47.5
+46.5
8.0
8.0
25
10.5
25
10.2
dB
dBm
:1
:1
V
A
L
Heat sink and fan not included. Alternative heat sinking and heat removal must be provided by the user to limit
maximum base-plate temperature to 85°C, in order to ensure proper performance. For reference, this requires thermal
resistance of user’s external heat sink to be 0.08°C/W max.
Outline Drawing
Maximum Ratings
Parameter
Operating Temperature
Storage Temperature
Base Plate Temperature
Input RF Power (no damage)
2
Ratings
-20°C to 85°C
-55°C to 100°C
85°C
3 dBm
2. At nominal output load, 24V nominal supply voltage.
Permanent damage may occur if any of these limits are exceeded.
Voltage +27V maximum.
MOUNTING INFORMATION FOR MODELS WITHOUT HEATSINK.
Outline Dimensions (
inch
)
mm
A
B
C
D
9.85
7.3
6.3
6.00
250.19 185.42 160.02 152.40
E
1.00
25.40
F
3.75
95.25
G
.13
3.30
H
__
__
J
.25
6.35
K
.63
16.00
L
1.03
26.16
M
__
__
N
__
__
P
3.25
82.55
Q
R
S
.5
6.00
5.1
12.70 152.40 129.54
T
wt
.135 grams*
3.43
4185
®
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
*500 grams without heatsink
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. C
M138727
ZHL-100W-52+
ED-12238/18
WZ/RS/CP/AM
130207
Page 1 of 2
Typical Performance Data/Curves
ZHL-100W-52+
FREQUENCY
(MHz)
GAIN
(dB)
DIRECTIVITY
(dB)
VSWR
(:1)
NOISE
FIGURE
(dB)
OUT
1.43
1.52
1.67
1.76
1.95
2.12
2.21
2.21
2.15
2.04
1.95
1.93
2.00
2.18
2.47
2.85
3.28
3.69
4.00
4.09
3.92
3.59
3.21
2.83
POUT
at 1 dB
COMPR.
(dBm)
24V
48.28
48.67
49.03
49.07
49.17
49.18
49.15
48.90
48.65
48.36
47.92
47.83
47.64
47.66
47.65
47.58
47.42
47.23
47.13
47.08
47.22
47.46
47.64
47.61
IP3
(dBm)
22V
50.00
70.00
90.00
100.00
120.00
140.00
160.00
180.00
200.00
220.00
240.00
260.00
280.00
300.00
320.00
340.00
360.00
380.00
400.00
420.00
440.00
460.00
480.00
500.00
49.98
50.09
50.12
50.19
50.24
50.25
50.21
50.09
49.97
49.82
49.59
49.45
49.32
49.26
49.28
49.38
49.55
49.76
49.98
50.13
50.18
50.12
49.94
49.70
24V
49.67
49.79
49.84
49.92
49.99
50.03
50.03
49.95
49.85
49.73
49.51
49.37
49.24
49.16
49.17
49.25
49.41
49.62
49.85
50.04
50.13
50.12
49.99
49.78
25V
49.50
49.63
49.68
49.77
49.85
49.90
49.92
49.85
49.78
49.66
49.45
49.31
49.17
49.09
49.09
49.16
49.32
49.52
49.76
49.96
50.07
50.07
49.96
49.78
24V
15.37
14.78
16.48
15.38
15.65
16.57
16.63
18.31
21.66
18.98
19.22
20.08
24.03
22.96
21.84
20.65
20.05
21.39
21.22
17.96
19.82
19.54
19.59
19.50
IN
1.37
1.28
1.27
1.29
1.34
1.40
1.47
1.52
1.56
1.59
1.59
1.58
1.52
1.45
1.37
1.27
1.17
1.14
1.24
1.42
1.60
1.74
1.78
1.70
24V
4.58
4.34
4.26
4.10
4.16
4.11
4.07
4.03
4.01
4.02
4.12
4.19
4.21
4.28
4.27
4.29
4.29
4.39
4.39
4.39
4.41
4.47
4.49
4.50
24V
61.24
61.60
61.85
61.94
61.85
60.85
60.47
60.06
59.28
58.10
57.44
57.06
56.91
56.73
56.36
56.38
56.10
56.25
56.28
56.66
56.74
57.16
56.90
56.81
ZHL-100W-52+
GAIN
53
DIRECTIVITY (dB)
52
GAIN (dB)
51
50
49
48
50
100
150
200
250
300
350
400
450
500
FREQUENCY (MHz)
22V
24V
25V
30
25
20
15
10
50
100
150
ZHL-100W-52+
DIRECTIVITY
5.0
4.0
VSWR (:1)
3.0
2.0
1.0
IN
ZHL-100W-52+
VSWR
OUT
200
250
300
350
400
450
500
50
100
150
200
250
300
350
400
450
500
FREQUENCY (MHz)
FREQUENCY (MHz)
ZHL-100W-52+
OUTPUT POWER at COMPRESSION
ZHL-100W-52+
NOISE FIGURE
5.0
NOISE FIGURE (dB)
4.6
4.2
3.8
3.4
3.0
IP3 (dBm)
63
61
59
57
55
ZHL-100W-52+
IP3
OUTPUT POWER (dBm)
50
49
48
47
46
45
50
100 150 200 250 300 350 400 450 500
FREQUENCY (MHz)
1dB Compr.
3dB Compr.
50
100
150
200
250
300
350
400
450
500
50
100
150
200
250
300
350
400
450
500
FREQUENCY (MHz)
FREQUENCY (MHz)
